STEPPED CUTTERS FOR PLATES
1192
13
Prices in EURO - VAT not included
8902G
HSS
TIN
12 steps.
For creating and enlarging holes in steel plate with thickness up to 4mm.
Interchangeable pilot bit Ø 7mm.
Cylindrical shank.
HSS, TIN coated.
Steps Ø
mm 25 28 31 34 37 40
43 46 49 52 55 58
Steps thickness
mm
4
Drive Ø
mm
12
Overall length
mm
85
8902G
Each
514,00
vuoto
Spare HSS+TIN pilot bit for Art. 8902 G.
O8902G
Each
52,90
vuoto
STEPPEDCUTTERSFORPLATES
8909G
8910G
HSS
Orig. Dürr
6-7 steps, particularly suitable for plumbers and electricians.
For drilling steel plate up to 6mm (Art. 8909 G) and up to 4mm (Art. 8910 G).
HSS. Cylindrical shank.
Interchangeable pilot bit Ø 7mm.
Art.
8909G
8910G
Steps Ø
mm 11,4 14 17,25 19
21,25 26,75
12,5 15,2 18,6 20,4
22,5 28,3 30,5
Steps thickness
mm
6
4
Drive Ø
mm
12
12
Overall length
mm
92
85
Supplier code
981-15
981-15
Each
177,00
169,00
vuoto
For spare pilot bit for Art. 8909 G – 8910 G see Art. O8896 G.
vuoto
STEPPEDCUTTERSFORPLATES
COUNTERSINKS WITH EXAGONAL SHANK 1/4
8910GA
new
8910GB
new
8910GC
new
HSS
1/4 ,,
Prod. SCU
The helical shape of the discharge improves drilling, reduces torque value, increases tool life,
eliminates vibrations and is also suitable for use with portable drills.
Hexagonal 1/4 - E 6.3 for use with screwdrivers, wrenches, drills, etc.
In steel SUPER-FAST HSS.
Art.
8910GA
8910GB
8910GC
Steps Ø
mm 4-5-6-7-8-9-10-11-12 4-6-8-10-12-14-16-18-
20
4-6-8-10-12-14-16-18-
20-22-24-26-28-30
Steps thickness
mm
4,5
5
4,5
Overall length
mm
70
80
110
Each
32,80
37,90
62,30
vuoto
COUNTERSINKSWITHEXAGONALSHANK1/4
HELICAL STEPPED CUTTERS FOR PLATES
8910GE
8910GF
8910GH
8910GL
HSS
Orig. Dürr
The helical shape of the discharge improves drilling, reduces the turning moment, increases tool
life, eliminates vibrations and is also suitable for use with portable drills.
HSS with nitrited surface. Cylindrical shank.
Art.
8910GE
8910GF
8910GH
8910GL
Steps Ø
mm 4 5 6 7 8 9 10
11 12
6 8 10 12 14 16
18 20
5 7 9 11 13 15
17 19
6 8 10 12 14 16 18
20 22 24 26 28 30
Steps thickness
mm 5
4,5
4,5
4
Drive Ø
mm 6
9
9
10
Overall length
mm 79
71
71
100
Supplier code
981-25
981-25
981-25
981-25
Each 63,80
73,70
77,80
128,00
vuoto
HELICALSTEPPEDCUTTERSFORPLATES
8910GMA
8910GME
8910GML
8910GMP
HSS
TIN
Product description as Art. 8910GE
HSS with TIN coating. Cylindrical shank.
Art.
8910GMA 8910GME
8910GML
8910GMP
Steps Ø
mm 4 5 6 7 8 9 10
11 12
6 8 10 12 14 16
18 20
5 7 9 11 13 15
17 19
6 8 10 12 14 16 18
20 22 24 26 28 30
Steps thickness
mm 5
4,5
4,5
4
Drive Ø
mm 6
9
9
10
Overall length
mm 79
71
71
100
Supplier code
981-25
981-25
981-25
981-25
Each 86,80
114,00
118,00
199,00
vuoto
HELICALSTEPPEDCUTTERSFORPLATES
