ELECTRONIC TORQUE WRENCHES, TORCO TRONIC
213
3
Prices in EURO - VAT not included
810GR
9x12 14x18
Orig. Gedore - Torcotronic III
Latest generation digital torque wrench used for TORQUE and ANGULAR measurements.
Microprocessor controls with CE marking. 1/2” reversible ratchet disc for tightening on the left and
on the right, removable via the ratchet insert keys and can be attached with female coupling
measuring 9x12 (as per Art. 810 GR 120) o mm 14x18 (Art. 810 GR 350). Graphic display with
rear lit liquid crystal display. Simple operation with menu icons and four function keys. Dual scale
in Nm and lbf.ft.
High level of measuring accuracy: ± 1% ±1 digit / ± 1% ±1° at 360° with a clamping speed to 4°/s.
Is able to program various measuring distances depending on the inserts which have been
installed. Keypad lock, visual display with 3 LEDs and a buzzer.
Equipped with items specified as per DIN ISO 6789:2003. Type I, Class C. Approved in
accordance with TÜV SÜD regulations. Comes complete with a large memory, which is also able
to measure modes and select 5 different clamping settings. Direct PC connection via USB cable,
software available on disk.
Batteries available in AA format (as per Art. SCU 3600 E) or with NiMH batteries.
Provided with casing.
Size
120
350
Inserts drive
mm 9x12
14x18
Tightening capacity
Nm 10-120
70-350
Tightening capacity
lbf.ft
7,4-88,5
51,6-258,2
Scale division
Nm 0,1 Nm/0,1°
0,1 Nm/0,1°
Overall length
mm 565
701
Weight
Kg
0,9
1,2
Supplier code
TT 3 KH 120 TT 3 KH 350
810GR
Each 1.950,00
2.050,00
In order to make full use of the wrench functions it must be connected to a PC with operating system WINDOWS XP or above.
vuoto
ELECTRONIC TORQUEWRENCHES,TORCOTRONIC
SOCKET RATCHETS FOR TORQUE WRENCHES
811G
Orig. Gedore
Sockets with built-in ratchet head to be used in combination with torque wrenches for controlled
clockwise tightening. Square female drive on one extremity, square male drive on the other
extremity.
Drive
inches
1/4
3/8
1/2
3/4
1
Overall height
mm 21
28
35
53
63
Ø
mm 24
35
46
65
73
Supplier code
754-00 754-01 754-02 754-04 754-06
811G
Each 116,00 121,00 155,00 230,00 596,00
Socket ratchets for counter clockwise torque wrenches on request.
vuoto
SOCKETRATCHETSFORTORQUEWRENCHES
PRECISION TORQUE MULTIPLIER
811GT
Prod. SCU
Mechanical torque multiplier of the tightening value set by the operator on the torque wrench. ±
5% tolerance. For bi-directional tightening.
Art. 811 GT 1680: with reaction bar.
Art. 811 GT 2700: with reaction foot.
Art. 811 GT 4500: with reaction bar.
Art. 811 GT 6000: with reaction foot and bar.
Art. 811 GT 9500: with reaction foot and bar.
Supplied in case.
Max tightening threshold
Nm
1680 2700 3500 4500 6000 9500
Int. panel for dynamometric key
inches 1/2
3/4
3/4
1/2
1/2
1/2
Ext. panel for bushes
inches 3/4
1
1
1.1/2 1.1/2 1.1/2
Multiplies force 1x
6
5,4
4,5
16
26
26
Drum Ø
mm 100
100
108
112
130
184
Overall height
mm 106
126
130
175
216
215
Weight
Kg
4,9
6,3
7,3
8,3
15,7
30,3
811GT
Each 1.210,00 1.370,00 2.730,00 3.870,00 6.740,00 12.630,00
Check the maximum load to choose the right torque multiplier.
