COMBINATION SPANNERS
230
3
Prices in EURO - VAT not included
874GD
874GE
Orig. Gedore - Art. 7
According to DIN 3113 A/3318.
In CHROME VANADIUM steel.
Bihexagonal head angled at 15°.
Finely worked. Chrome plated finish.
Opening
mm
3
3,2
3,5
4
4,5
5
5,5
6
7
8
9
10
Heads thickness
mm 2,8x2,8 2,8x2,8 2,8x2,8 3,2x3,2 3,2x3,2 3,6x3,6 3,6x3,6 3,4x5 3,6x5,5 3,8x6 4x6,5 4,2x7
Overall length
mm 78
78
78
85
85
92
92
100
110
120
130
140
874GD
Each 12,50 12,80 12,50 12,50 12,50 12,50 12,50
8,36
8,24
8,72
9,00
8,76
Opening
mm
11
12
13
14
15
16
17
18
19
20
21
22
Heads thickness
mm 4,5x7,5 4,8x8 5x8,5 5,2x9 5,5x9,5 5,8x10 6x10,5 6,2x11 6,5x11,5 6,8x12 7x12,5 7,2x13
Overall length
mm 150
160
170
180
190
200
210
220
230
240
252
262
874GD
Each 9,64
10,30 10,40 11,10 11,90 12,70 12,80 14,60 14,30 17,30 17,70 19,80
Opening
mm
23
24
25
26
27
28
29
30
32
34
36
Heads thickness
mm 7,6x13,5 8x14 8,2x14,5 8,2x15 8,5x15,5 8,8x16 8,8x16,5 9x17 9,5x18 10x19 10,5x20
Overall length
mm 270
282
290
302
310
320
330
340
380
420
460
874GD
Each 20,50 22,20 23,10 23,60 25,80 29,50 30,20 30,70 33,70 44,80 66,10
Dimensions: 3-3,2-3,5-4-4,5-5-5,5 mm, hexagonal rings instead of polygonal rings.
vuoto
Product description as Art. 874GD
MODEL WITH OPENINGS IN US INCH SIZES
Opening
inches
1/4 5/16 11/32 3/8 7/16 1/2 9/16 5/8 11/16 3/4 13/16 7/8 15/16
1
Heads thickness
mm 3,4x5 3,8x6 4x6,5 4,2x7 4,5x7,5 5x8,5 5,2x9 5,8x10 6,2x11 6,5x11,5 7x12,5 7,2x13 8x14 8,2x15
Overall length
mm 100 120 130 140 150 170 180 200 220
230
252 262 282 302
874GE
Each 9,84 9,94 10,10 10,30 10,80 12,10 12,80 14,70 16,70 17,30 19,60 22,10 25,30 24,80
vuoto
COMBINATIONSPANNERS
874GL
Orig. Gedore - Art. 7XL
LONG pattern.
According to DIN 3113.
In CHROME VANADIUM steel.
Bihexagonal head angled at 15°.
Finely worked. Chrome plated finish.
Opening
mm
7
8
9
10
11
12
13
14
15
16
17
18
Heads thickness
mm 4,5x7 4,5x7 4,5x7,5 5x8,5 5,5x9 5,5x10 6x10,5 6,5x10,8 7x11,2 7,5x11,8 8,5x12,2 8,5x13,2
Overall length
mm 170
170
180
190
200
210
225
235
250
265
280
295
874GL
Each 12,10 12,00 13,70 13,60 13,60 13,60 13,60 16,40 16,40 19,30 19,30 23,80
Opening
mm
19
21
22
24
27
30
32
33
34
36
41
46
Heads thickness
mm 9,5x14,2 9,5x14,2 11x16,2 12x18,2 13x20,2 14x21,2 14x22,2 15x23,2 15x23,2 15x24,2 16x26 17x28
Overall length
mm 310
340
350
400
450
480
500
520
520
550
600
640
874GL
Each 23,80 27,40 27,40 30,40 39,10 63,60 76,80 96,30 97,30 96,90 108,00 175,00
vuoto
COMBINATIONSPANNERS
874GR
Orig. Carolus - Art. 09
According to DIN 3113 A.
In CHROME VANADIUM steel.
Bihexagonal head angled at 15°.
Chrome plated finish.
Opening
mm
6
7
8
9
10
11
12
Heads thickness
mm 3,4x5 3,6x5,5 3,8x6 4x6,5 4,2x7 4,5x7,5 4,8x8
Overall length
mm 100
110
120
130
140
150
160
874GR
Each 4,12
4,12
4,12
4,12
4,34
4,72
5,18
Opening
mm
13
14
15
16
17
18
19
Heads thickness
mm 5x8,5 5,2x9 5,5x9,5 5,8x10 6x10,5 6,2x11 6,5x11,5
Overall length
mm 170
180
190
200
210
220
230
874GR
Each 5,18
5,64
5,86
6,32
6,32
7,62
7,62
Opening
mm
20
21
22
24
27
30
32
Heads thickness
mm 6,8x12 7x12,5 7,2x13 8x14 8,5x15,5 9x17 9,5x18
Overall length
mm 240
252
262
282
310
340
370
874GR
Each 9,06
9,36
9,98 11,50 15,70 16,40 19,70
Opening
mm
34
Heads thickness
mm 10x19
Overall length
mm 420
874GR
Each 26,60
