ALLEN HEAD SCREW WRENCHES
263
3
Prices in EURO - VAT not included
914G
Orig. Gedore - Art. 42
In CHROME VANADIUM steel, chrome plated finish DIN ISO 2936. Rounded off heads for a
perfect fit with the screw.
Hexagon
mm
0,7
0,9 1,3
1,5
2
2,5
3
4
Overall length
mm 33
33
41 46,5 52 58,5 66
74
For screws Ø
mm -
-
-
2
2,5
3
4
5
914G
Each 1,00 1,00 0,84 0,84 0,78 0,80 1,16 1,58
Hexagon
mm
5
5,5
6
7
8
9
10
12
Overall length
mm 85
85
96
102 108 114 122 137
For screws Ø
mm 6
-
8
9
10
11
12
14
914G
Each 1,58 1,86 1,64 2,14 2,70 3,32 4,22 6,18
Hexagon
mm
14
17
19
22
24
27
30
32
Overall length
mm 154 177 199 222 248 277 315 347
For screws Ø
mm 16-18 20-22 24-27 30
33
36
-
48
914G
Each 11,70 18,60 21,20 30,80 38,20 53,40 77,60 110,00
vuoto
ALLENHEADSCREWWRENCHES
914GA
Product description as Art. 914G
Hexagonal heads in US inch sizes.
Hexagon
inches
3/64 1/16 5/64 3/32 1/8 5/32 3/16 7/32
Hexagon
mm 1,19 1,59
2
2,38 3,17 3,97 4,76 5,5
914GA
Each 0,80 0,80 0,78 0,78 0,98 1,52 1,78 1,86
Hexagon
inches
1/4 5/16 3/8
1/2 9/16 5/8 3/4
Hexagon
mm 6,35 7,94 9,52 12,7 14,29 15,87 19,05
914GA
Each 1,78 2,58 3,74 6,66 11,30 14,70 22,10
vuoto
ALLENHEADSCREWWRENCHES
914GAP
Prod. SCU
In special steel, chromated finish. Fine quality with rounded off head for a perfect fit with the
screw.
Hexagonal heads in US inch sizes.
Hexagon
inches
3/64
0.05
1/16
5/64
3/32
1/8
5/32
Hexagon
mm 1,19
1,27
1,59
1,98
2,38
3,18
3,97
914GAP
Each 0,10
0,10
0,10
0,12
0,12
0,16
0,28
Hexagon
inches
3/16
7/32
1/4
5/16
3/8
1/2
9/16
Hexagon
mm 4,76
5,56
6,35
7,94
9,53
12,7 14,29
914GAP
Each 0,30
0,42
0,52
1,06
1,84
3,36
3,98
Hexagon
inches
5/8
3/4
1
Hexagon
mm 15,88 19,05 25,4
914GAP
Each 5,74
9,88 27,10
vuoto
ALLENHEADSCREWWRENCHES
914GB
Orig. Gedore - Art. 42EL
Extra-long model.
In CHROME VANADIUM steel, chrome plated finish DIN ISO 2936. Rounded off heads for a
perfect fit with the screw.
Hexagon
mm
2
2,5
3
4
5
6
8
Overall length
mm 102 114,5 129
144
165
186
208
For screws Ø
mm 2,5
3
4
5
6
8
10
914GB
Each 1,72
1,72
2,20
2,52
3,28
4,16
6,00
Hexagon
mm
10
12
14
Overall length
mm 234
262
294
For screws Ø
mm 12
14
16-18
914GB
Each 10,50 14,50 21,40
vuoto
ALLENHEADSCREWWRENCHES
914GBA
Prod. SCU
Extra-long model.
In special steel, chromated finish. Fine quality with rounded off heads for a perfect fit with the
screw.
Hexagon
mm
1,5
2
2,5
3
4
5
6
Overall length
mm 91
102
114
129
144
165
186
For screws Ø
mm 2
2,5
3
4
5
6
8
914GBA
Each 0,22
0,22
0,24
0,30
0,44
0,84
1,10
Hexagon
mm
8
10
12
14
17
19
Overall length
mm 208
234
262
294
337
379
For screws Ø
mm 10
12
14
16-18 20-22 24-27
914GBA
Each 1,98
3,24
4,76
7,70 13,60 17,20
vuoto
