RACK AND PINION JACKS
627
8
Prices in EURO - VAT not included
2228GBN
Manufactured in compliance with DIN 7355 standards. Completely made of steel. Bolted body
can be easily disassembled and inspected. Steel gears with hardened interchangeable operating
parts, Maximum safety and duration. Safety winch to brake descent. Lateral support and upper
support with the same load capacity.
With safety winch.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 350
350
300
300
Max height as closed
mm 725
725
725
800
Weight
Kg
12
20
24
42
2228GBN
Each 509,00
577,00
679,00 1.070,00
vuoto
RACKANDPINION JACKS
2228GCN
Product description as Art. 2228GBN
With safety winch and cric.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 350
350
300
300
Max height as closed
mm 725
725
725
800
Weight
Kg
12
20
24
42
2228GCN
Each 579,00
646,00
749,00 1.150,00
vuoto
RACKANDPINION JACKS
2230GN
Manufactured in compliance with DIN 7355 standards. Steel gears with hardened
interchangeable operating parts. With movable support. It allows to place the jack quickly by using
all the available stroke. Safety winch. Movable support and upper support with the same load
capacity.
Max load capacity
Kg
3000
5000
10000
Ratio
simple
double
double
Stroke
mm 350
300
300
Max height as closed
mm 725
725
800
Weight
Kg
23
29
46
2230GN
Each 712,00
848,00 1.270,00
vuoto
RACKANDPINION JACKS
2232GN
Manufactured in compliance with DIN 7355 standards. Completely made of steel. Bolted body
can be easily disassembled and inspected. Steel gears with hardened interchangeable operating
parts. Safety winch. With in-and-out clamping bracket to hold tracks, section bars, billets, etc.
Lateral upport and upper support with the same load capacity. Enlarged base allows working in
small consistency grounds.
Max load capacity
Kg
3000
5000
10000
Ratio
simple
double
double
Stroke
mm 340
300
300
Max height as closed
mm 715
715
790
Weight
Kg
23
26
44
2232GN
Each 532,00
617,00
966,00
vuoto
RACKANDPINION JACKS
BÜFFEL HYDRAULIC JACKS
2240G
Orig. Weber - Art. B
Manufactured in compliance with European standards. Hydraulic operated. Completely made of
steel, operating parts in special hardened steel and chromed piston. Special indeformable
gaskets. 360° rotating body. Provided with overload safety valve. Lower support base, square and
flat, with dimensions 100x100mm, interchangeable, with reduced movement lever, 360° rotation.
Lateral support foot, 4-positions adjustable (for 10.000kg 6 positions). Particularly indicated for
heavy use where big weights are to be handled with minimum effort. It can be used in any
position.
Max load capacity
Kg
5000 10000
Stroke
mm 280
350
Max height as closed
mm 650
800
Weight
Kg
26
38
2240G
Each 3.650,00 4.320,00
vuoto
BÜFFELHYDRAULIC JACKS
