694 / 1378
694
MACHINE VICES
694
9
Prices in EURO - VAT not included
2874GE
Product description as Art. 2874G
Jaw extension rapid adjustment
Jaws width
mm
50
75
100
Max opening
mm 70
100
125
Jaws height
mm 25
35
45
Overall length
mm 140
190
246
Weight
Kg
1,6
3,9
9,5
Supplier code
06066056 06066057 06066058
2874GE
Each 144,00
187,00
316,00
vuoto
MACHINEVICES
PARALLEL COUPLES
2879
Prod. SCU
In hardened special steel, HRc 60 hardness. Ground and lapped in couple. Precision: 0.005mm.
Specific for mechanical works such as parallel tightening, as vice resting, etc. Overall lenth
Lunghezza totale parallele 150mm.
The set consists of Nr. 14 couples having the following thickness x width:
10x14 - 10x16 - 10x18 - 10x20 - 10x22 - 10x24 - 10x26 - 10x28 - 10x30 - 10x32 - 10x35 - 10x40 -
10x45 - 10x50mm.
Supplied in wooden case.
2879
Each 302,00
vuoto
PARALLELCOUPLES
ANVILS
2883
Prod. SCU
In moulded cast iron, with hardened and enamelled working surface.
Suited to mechanics and fine mechanics.
Weight approx.
Kg
2,5
5
10
20
30
50
Dimensions
mm 190x53 250x65 330x80 480x110 525x120 603x146
Height approx.
mm 68
94
100
135
155
167
2883
Each 32,10 58,70 115,00 218,00 328,00 551,00
vuoto
ANVILS
2884
In moulded steel, with hardened and polished working surface.
Suited to mechanics and fine mechanics.
Weight approx.
Kg
10
20
30
40
50
60
80
Dimensions
mm 360x90 465x105 515x120 600x130 630x140 665x150 745x170
Height approx.
mm 96
140
145
170
190
205
220
2884
Each 172,00 355,00 497,00 632,00 767,00 923,00 1.180,00
Weight approx.
Kg
100
Dimensions
mm 800x180
Height approx.
mm 240
2884
Each 1.510,00
vuoto
ANVILS
2885G
Orig. KANCA
In forged and hardened steel, monoblock.
The special basament shape assures max. stability even when anvil extremities are stricken.
Working surface hardness from 54 to 62 HRc.
With 1 square hole and 1 round hole for possible fixing plugs.
Weight approx.
Kg
20
35
50
75
Dimensions
mm 390x80 470x95 550x110 625x125
Height approx.
mm 155
200
220
265
Square bore side
mm 22
22
25
25
Round bore Ø
mm 20
20
23
23
2885G
Each 337,00 589,00 841,00 1.270,00
vuoto
ANVILS
MACHINIST’S SCRAPERS
2908G
Prod. SCU
Insulated type with triangular blade in chrome plated steel, hardened, hardness 58-62 HRc.
Handle in synthetic material.
Suited to mechanics and fine mechanics. Blade dimensions: 80x8mm.
2908G
Each 16,50
vuoto
MACHINIST’SSCRAPERS
2909G
Type with triangular blade in chrome plated steel, hardened, hardness 58-62 HRc. Wooden
handle. Suited to mechanics and fine mechanics.
Blade dimensions: 75x7mm.
2909G
Each 6,72
vuoto
MACHINIST’SSCRAPERS
