PILLAR DRILLS WITH MAGNETIC SUPPORT
718
9
Prices in EURO - VAT not included
PILLAR DRILLS WITH MAGNETIC SUPPORT
3078G
Prod. SCU
Angular-type, feeding through a lever that can be installed on both sides of the drilling machine.
Suitable for drilling in confined areas. Sturdy manufacture, compact and handy, with magnetic
support for vertical, horizontal and upside down use. 230 V-50/60 Hz monophase motor with
overload safety switch included. Equipped with locking device to avoid accidental start-up before
the magnet is installed. Manual lubrication (see Art. 3100 M). Weldon shank Ø 19mm. In practical
transport case.
Single speed.
Boring capacity with cutting mills mm 12 to 35
Magnet traction force
N 15000
Magnet dimensions
mm 160x80
Power
W 1100
No-load speed
rev/min 650
Height
mm 200
Max cutting depth
mm 30
Weight
Kg
10
3078G
Each 1.040,00
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
3078GA
Sturdy manufacture, compact, light, with magnetic support for vertical, horizontal and upside
down use. 230 Volt monophase motor with overload safety switch included. Equipped with locking
device to avoid accidental start-up before the magnet is installed. Automatic lubrication. Weldon
shank Ø 19mm. In practical case.
Single speed.
Boring capacity with cutting mills mm 12 to 35
Bores with tips up to
mm 13
Magnet traction force
N 15000
Magnet dimensions
mm 160x80
Power
W 1100
No-load speed
rev/min 620
Height
mm 400
Max cutting depth
mm 50
Weight
Kg
12
3078GA
Each 956,00
vuoto
Adapter complete with three-jaw chuck, opening 1,5-13mm, for drill Art. 3078 GA.
O3078GB
Each 30,50
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
3078GE
Sturdy manufacture, compact, steady, with magnetic support for vertical, horizontal or upside
down use. 230 V-50 Hz mono-phase motor with overload safety switch included. Equipped with
locking device to avoid accidental start-up before the magnet is installed. Automatic lubrication.
Weldon shank Ø 19mm. In handy case.
Double speed.
Boring capacity with cutting mills mm 12 to 50
Bores with tips up to
mm 16
Magnet traction force
N 32000
Magnet dimensions
mm 200x100
Power
W 1800
No-load speed
rev/min 380/500
Height
mm 495
Max cutting depth
mm 75
Weight
Kg 22,9
3078GE
Each 1.640,00
vuoto
Adapter complete with three-jaw chuck, opening 1-16mm, for drill Art. 3078 Ge.
O3078GE
Each 34,30
vuoto
