809 / 1378
809
BARREL PVC PUMPS
809
10
Prices in EURO - VAT not included
BARREL PVC PUMPS
3427R
Prod. SCU
Apt for naphtha, diesel fuel, kerosene. With filter and ballgrip.
Takeup pipe length
mm
750
1000
3427R
Each 23,40 24,90
vuoto
BARRELPVCPUMPS
BARREL PUMPS FOR FUELS
3427S
Prod. SCU
Lever-operated pump with diaphragm. Body in special synthetic material, diaphragm in Viton and
metal components in stainless steel. Can work both in horizontal and vertical position by fastening
it with 4 screws or directly on the barrel by means of bung adaptor G 2". Supplied without tubes,
but arranged for 3 connections Ø 27-33-38mm. Suction tube max length: 5m, delivery hose max
length: 8m. For gasoline, fuels in general, fuel oils and water. Max length when closed: 350mm.
Output: 40l/min. Weight: 0.750kg
3427S
Each 170,00
vuoto
BARRELPUMPSFOR FUELS
BARREL PUMPS FOR LIQUIDS
3427SE
Prod. SCU
Lever-operated pump with diaphragm. Body in special synthetic material, highly corrosion-
resistant. Can work both in horizontal and vertical position (wall-mounted), or directly on barrels
by means of the special support with bung adaptor M 64x4 and G 2". Suction tube length: about
1.20m, with filter. Delivery hose length: about 2m, with nozzle. Fastening screws and ties in
stainless steel.
Output: 25l/mm. Weight: 2.95kg. Operating temperature: -10° to +40° C.
Apt for water, seawater, diesel oil, mineral and synthetic oil, engine oil, glycol (anti-freeze),
dielectric liquid (kerosene), heating oil, emulsions.
3427SE
Each 89,10
Pumps suitable for decanting liquid foodstuffs are available on request.
vuoto
BARRELPUMPSFOR LIQUIDS
BARREL PUMPS
3427T
Prod. SCU
Lever-operated pump with metal body.
Bung adaptor G 2".
Suction telescopic tube max length: 900mm approx.
Liquids output PVC hose with max length: 1000mm approx.
Apt for naphtha, diesel fuel and all fluid oils.
Not apt for solvents, detergents, acids and gasoline.
Output: 30l/min.
3427T
Each 82,50
vuoto
BARRELPUMPS
3428GB
Orig. Hallbauer
Professional type, lever-operated pump with heavy metal body.
Connecting thread M 64x4 and bung adaptor G 2".
Suction telescopic tube max length: 900mm approx. Output: 0.5l per stroke. PVC hose length: 2m
with spout and anti-bending spring. Apt for naphthta, diesel fuel and all fluid and thick oils. Not apt
for solvents, detergents, acids and gasoline.
3428GB
Each 74,10
vuoto
BARRELPUMPS
