849 / 1378
849
HOSE CLAMPS
849
10
Prices in EURO - VAT not included
3474FN
INOX
Product description as Art. 3474EN
Width 12mm. Locking torque Nm 6.
Capacity
mm
16-27 20-32 25-40 30-45 32-50 40-60 50-70
3474FN
Each 1,26
1,32
1,32
1,38
1,50
1,50
1,56
Capacity
mm
60-80 70-90 80-100 90-110 100-120 110-130 120-140
3474FN
Each 1,88
2,02
2,14
2,42
2,52
2,52
2,62
Capacity
mm
130-150 140-160 150-170 160-180 170-190 180-200
3474FN
Each 2,76
2,84
2,94
3,04
3,62
3,98
vuoto
HOSECLAMPS
3474G
INOX
model DIN 3017, 316 stainless steel, W 5. Drawn band, rounded edges and raised. Screw with
Hexagon mm 7.
Width 9mm. Locking torque 4.5 Nm.
Suitable for the food, maritime, petrochemical sector etc.
Capacity
mm
8-12 10-16 12-20 16-25 20-32 25-40 32-50
3474G
Each 1,24
1,30
1,32
1,48
1,52
1,60
1,68
Capacity
mm
40-60 50-70 60-80 70-90 80-100
3474G
Each 1,76
1,86
1,94
2,04
2,12
vuoto
HOSECLAMPS
3474H
INOX
Product description as Art. 3474G
Width 12mm. Locking torque 6 Nm.
Suitable for the food, maritime, petrochemical sector etc.
Capacity
mm
16-27 20-32 25-40 30-45 32-50 40-60 50-70
3474H
Each 2,10
2,16
2,26
2,26
2,38
2,50
2,62
Capacity
mm
60-80 70-90 80-100 90-110 100-120 110-130 120-140
3474H
Each 2,98
3,12
3,26
3,38
3,50
3,64
3,78
Capacity
mm
130-150 140-160 150-170 160-180 170-190 180-200
3474H
Each 3,88
4,02
4,02
4,26
4,26
4,26
vuoto
HOSECLAMPS
3474L
Collar type.
In W1 galvanized steel, band in one smooth unit, round esges.
Width: 9mm. Ensure a low driving torque. Suitable for automotive industry, household appliances,
gas system components , etc.
Capacity
mm
7-9
8-10
9-11 10-12 11-13 12-14 13-15
3474L
Each 0,32
0,32
0,32
0,32
0,32
0,32
0,32
Capacity
mm
14-16 15-17 16-18 17-19 18-20 19-21
3474L
Each 0,32
0,32
0,32
0,32
0,32
0,32
vuoto
HOSECLAMPS
BAND, HOSE CLAMPS
3474LG
Prod. SCU
Suitable for frequent clamping, non-heavy applications. Suitable for hose clamps Art. 3474 BN -
CN - EN - FN - L as well for any hose clamp with hexagonal screw, opening 7mm.
HOSE CLAMP PLASTIC KEYS
3474LG
Each 0,62
vuoto
BAND,HOSECLAMPS
HOSE CLAMPS WITH RUBBER
3474M
Prod. SCU
Type in W1 galvanized steel, smooth band with raised edges and hex-end screw. The bolt is
directly fixed on the threaded barrel, therefore collars can be tighten with electric or pneumatic
screwdrivers.
Ensure high clamping capacities. To be employed in agruculture, building, hydraulic sectors, etc.
Capacity Ø
mm
23-25 26-28 29-31 32-35 36-39 40-43 44-47
Screw
M 6
6
6
6
6
6
6
Belt width x thickness
mm 20x0,6 20x0,6 20x0,6 20x0,6 20x0,6 20x0,6 22x0,8
3474M
Each 1,30
1,30
1,34
1,38
1,72
1,80
1,80
Capacity Ø
mm
48-51 52-55 56-59 60-63 64-67 68-73 74-79
Screw
M 6
6
6
6
6
8
8
Belt width x thickness
mm 22x0,8 22x0,8 22x0,8 22x0,8 22x0,8 24x0,8 24x0,8
3474M
Each 1,82
1,84
1,86
1,90
1,94
2,04
2,08
Capacity Ø
mm
80-85 86-91 92-97 98-103 104-112 113-121 122-130
Screw
M 8
8
8
8
8
8
8
Belt width x thickness
mm 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8
3474M
Each 2,16
2,20
2,24
2,26
2,34
2,62
3,60
Capacity Ø
mm
131-140 140-148 149-161 162-174 175-187 188-200
Screw
M 10
10
10
10
10
10
Belt width x thickness
mm 26x1 26x1 26x1 26x1 26x1 26x1
3474M
Each 3,68
3,80
3,98
4,02
4,14
4,40
vuoto
HOSECLAMPSWITHRUBBER
