PRECISION EXTERNAL ELECTRONIC MICROMETERS
885
11
Prices in EURO - VAT not included
PRECISION EXTERNAL ELECTRONIC MICROMETERS
3791G
IP54
HARTMETALL
1/1000
Orig. MIB
Precision and wide measuring range model. Contact surfaces in hardmetal.
Interchangeable measuring rods. Absolute and relative linear measurement function.
Ratchet inserted in the thimble for uniform pressure of hardmetal contact surfaces.
Direct reading on display 0.001 mm.
1,5 V Battery operated. Setting gauge supplied in case together with the micrometer.
Capacity
mm
0-150 150-300
Supplier code
02032060 02032061
3791G
Each 424,00 474,00
vuoto
PRECISIONEXTERNALELECTRONICMICROMETERS
PRECISION EXTERNAL ELECTRONIC MICROMETERS
3791GB
Orig. MIB
In hardened steel.
Suitable for calibration of micrometer for outdoor use.
Ground and lapped ends.
Heat insulated handles.
Overall length
mm
25
50
75
100
125
150
Parallelism precision
µm ±
2
2
2
2,5
2,5
3
Supplier code
01018050 01018051 01018052 01018053 01018054 01018055
3791GB
Each 15,80
15,80
15,80
19,10
23,70
23,70
Overall length
mm
175
200
225
250
275
Parallelism precision
µm ±
3
3,5
3,5
3,5
3,5
Supplier code
01018056 01018057 01018058 01018059 01018060
3791GB
Each 23,70
23,70
31,60
31,60
31,60
vuoto
PRECISIONEXTERNALELECTRONICMICROMETERS
SCREW-THREAD MICROMETERS
3791GF
1/100
Orig. MIB
Precision according to DIN 863. With advance rod for crozes and conical inserts, whitch are able
to rotate.
Suitable to measure external threads diameters at 60° (metric thread/UNF) and at 55° (Ww).
Matt graduating parts. Increments in 1/100 mm.
Sensitive screw, locking lever and athermic gripping pads.
Supplied without crozes and conical inserts.
Supplied in case.
Capacity
mm
0-25
25-50
50-75 75-100
Supplier code
01019080 01019081 01019082 01019083
3791GF
Each 237,00 254,00 273,00 295,00
vuoto
SCREW-THREADMICROMETERS
3791GL
60
Couple of crozes and conical inserts for threading at 60° (metric and UNF).
For micrometers Art. 3791 GF.
Pitch
mm
0,4 - 0,5 0,6 - 0,9 1 - 1,75 2 - 3
3,5 - 5 5,5 - 7
Supplier code
01019084 01019085 01019086 01019087 01019088 01019089
3791GL
Per pair
31,60
31,60
31,60
31,60
31,60
31,60
Couple of crozes for Whitworth thread 55° and adjusting rods 25-50-75mm
(at 60° and 55°) are supplied on request.
vuoto
SCREW-THREADMICROMETERS
PRECISION MICROMETERS FOR MEASURING GEARINGS
3792GA
1/100
Orig. MIB
Precision type.
Advance rod Ø 8mm, in hardened and ground steel. Oversize discs.
Suitable to measure thikness, width and distance of gear and tool teeth, both linear and angled.
Matt chrome plated graduated parts. Increments in 1/100 mm. Sensitive screw and heatproof
gripping pads. Setting gauge 25mm onwards. Supplied in case.
Capacity
mm
0-25
25-50
50-75 75-100
Plate Ø
mm 20
20
20
20
Supplier code
01019096 01019097 01019098 01019099
3792GA
Each 114,00 132,00 145,00 171,00
Available also with discs Ø 60mm on request.
