893 / 1378
893
THICKNESS MEASURING INSTRUMENTS
893
11
Prices in EURO - VAT not included
3955G
1/100
Prod. SCU - Orig. Käfer
Professional model, increments in 1/100 mm, sensitive lever.
Automatic recoil. Effective opening 10mm. Wide dial for easy reading with two indicators for
millimiters, 1/10 millimiters and 1/100 millimiters. Round flat contact surface Ø 10mm. Soft touch,
calibrated keys.
Arch depth
mm
50
100
200
3955G
Each 239,00 301,00 362,00
On request also available with flat round discs Ø 20mm, 30mm, crowned or tipped discs.
vuoto
THICKNESSMEASURING INSTRUMENTS
3956G
1/100
Professional model, roller contact surface, width 8.7mm and diameter 8.4mm. Effective opening
5mm. Bow depth 50mm. Particularly suited to measure the thickness of cables, wire, bands, etc.
Increments in 1/100 mm, sensitive lever and automatic recoil. Wide dial dor easy reading with two
indicators for millimiters, 1/10 millimiters and 1/100 millimiters.
3956G
Each 449,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3956GA
1/100
Professional model, rollers and runners contact surface, width 8.7mm and diameter 8.4mm.
Effective opening 5mm. Bow depth 50mm. Particularly suited to measure the thickness of cables,
wire, bands, etc. Increments in 1/100 mm, sensitive lever and automatic recoil. Wide dial dor easy
reading with two indicators for millimiters, 1/10 millimiters and 1/100 millimiters.
3956GA
Each 449,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3958
1/100
Increments in 1/100 mm, with sensitive lever and automatic recoil.
Particularly suited to measure the thickness of linings and tappets in the automotive sector.
Lower flat basement and contact surface, ball upper contact surface.
Bow depth 50mm, effective opening 10mm.
3958
Each 112,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3959G
1/1000
Professional model, highly precise. Increments in 1/1000 mm.
Particularly suited to measure sheets of very thin thicknessf.
Insulated handle to avoid hand heat influence. Controlled pressure force of approx. 2 Nm. Bow
depth 30mm. Effective opening 1mm (one indicator revolution corresponds to 0.2mm). Flat round
contact surface Ø 6.3mm.
3959G
Each 439,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3960G
1/10
5/100
Particularly suited to measure saw teeth alternation.
4 contact surfaces to directly show on display the position of the alternate tooth. Increments in 1/
10 mm and + 5/100 mm.
Measuring range 2mm.
Taster diameter mm 10.
3960G
Each 110,00
vuoto
THICKNESSMEASURING INSTRUMENTS
