UNIVERSAL GONIOMETERS
904
11
Prices in EURO - VAT not included
UNIVERSAL GONIOMETERS
4022B
Prod. SCU
In hardened and ground stainless steel. Easy and accurate graduation reading. Indelible laser
marked degree increments.
Ring nut locking goniometer arm. Matt chrome finish.
Rule with through slot.
Arch Ø (mm)
mm
120
150
200
250
300
Rod length
mm 240
300
400
500
600
4022B
Each 30,70 37,10 44,10 84,50 120,00
vuoto
UNIVERSALGONIOMETERS
4022G
In hardened and ground stainless steel. Easy and accurate graduation reading.
Indelible mechanical marked degree increments.
Goniometer arm screw lock. Matt chrome finish.
Precision model with non-through slot.
Arch Ø (mm)
mm
100
150
200
250
300
Rod length
mm 150
300
400
500
600
4022G
Each 38,70 45,40 52,90 72,40 93,40
vuoto
UNIVERSALGONIOMETERS
UNIVERSAL BEVEL PROTRACTORS
4026GB
INOX
1/12
Prod. SCU
In stainless steel, hardened and ground. 360° scale,
four scale reads 0° to 90°.
Easy and accurate graduation reading. Vernier scale in 1/12 degree increment.
Sliding rod length
mm 300
4026GB
Each 75,70
vuoto
UNIVERSALBEVELPROTRACTORS
BEVEL PROTRACTORS
4028
INOX
1/12
Prod. SCU
Made from stainless steel, hardened and ground. Easy reading thanks to the magnifying lens.
Matt 360° chrome plated scale divided into four sections from 0° to 90°. 1/12 degree nonius,
parallax-free readings. Fine adjustment using a micrometer screw. With supplementary adjustable
square and 150 - 200 - 300mm sliding rules.
Boxed.
4028
Each 89,30
vuoto
BEVELPROTRACTORS
4028G
4028GA
4028GB
1/12
INOX
High-precision execution.
In stainless steel, hardened and ground.
Panoramic magnifier, 360° matt chrome plated, four 0° to 90° reading graduation. Vernier scale in
1/12 degree increments without parallax errors. Fine adjustment through micrometer screw.
Supplied in case.
Art.
4028G 4028GA 4028GB
Sliding rod length
mm 150
300
500
Each 242,00 259,00 312,00
The electronic digital version is available on request.
vuoto
BEVELPROTRACTORS
BEVEL PROTRACTORS WITH DIAL INDICATOR
4031
INOX
1/12
Orig. MIB - Art. 05060012
In stainless steel, hardened and ground.
Dial indicator. Four 0° to 90° reading graduation.
Vernier scale in 1/12 degree increments. Supplied in case.
Sliding rod length
mm 300
4031
Each 137,00
vuoto
BEVELPROTRACTORSWITHDIAL INDICATOR
PERIMETER SPECIAL STEEL MEASUREMENTS
4036G
1/10
Orig. MIB - Art. 07074065
For direct measuring of perimeters and diameters.
Vernier scale reading 0.1 mm. Precision according to DIN 2768 m.
In special steel, flexible.
Size
6
Circumpherence capacity mm 5960-7230
Capacity Ø
mm 1900-2300
4036G
Each 244,00
Product running out of stock.
