928 / 1378
928
PRECISION ADJUSTABLE HAIR SQUARE
928
11
Prices in EURO - VAT not included
PRECISION ADJUSTABLE HAIR SQUARE
4267G
875/0
Prod. SCU
In hardened steel, lapped measuring parts. Accuracy according to DIN 875/0. Romboidal ruler
60x4x4mm, adjustable. Base dimensions 40x22x10mm.
Particularly suitable for tool manufacturers, fine mechanics, diesinkers, etc.
Supplied in case.
4267G
Each 148,00
vuoto
PRECISIONADJUSTABLEHAIRSQUARE
MULTIDEGREES SQUARE
4267GA
1/25
Orig. MIB
In steel. Ground and finely polished.
Accuracy: 1/25°. With back. With following angles: 120° - 90° - 45° - 30°.
Long side length
mm
100
120
150
Supplier code
03043080 03043081 03043082
4267GA
Each 47,40
55,30
63,20
vuoto
MULTIDEGREESSQUARE
4267GB
875/II
Prod. SCU
In steel. Finely polished.
Accuracy according to DIN 875/II.
Standard execution. 120° angle.
Dimensions
mm
50x50 75x75 100x100
Section
mm 15x5 18x5 20x5
4267GB
Each 20,30 24,80 31,00
vuoto
MULTIDEGREESSQUARE
4267GD
875/II
Product description as Art. 4267GB
Standard execution. 135° angle.
Dimensions
mm
50x50 75x75 100x100
Section
mm 15x5 18x5 20x5
4267GD
Each 20,30 24,80 31,00
vuoto
MULTIDEGREESSQUARE
PRECISION CENTERING SQUARES
4267GE
875/I
Prod. SCU
In steel. Finely ground, chrome plated. Graduations in millimitersm. Angle bisector accuracy
according to DIN 875/I. Suitable for 45° and 90° angles, for locating round centres and for tracing.
Dimensions
mm
100x70 150x130 200x150
For shafts up to Ø
mm 90
190
220
4267GE
Each 43,50 52,50 64,20
vuoto
PRECISIONCENTERINGSQUARES
FLANGE SQUARES
4267GF
Prod. SCU
In steel, polished surface.
Dimensions
mm
300x300 500x500
Section
mm 30x5 30x5
4267GF
Each 23,10 34,80
vuoto
FLANGESQUARES
4267L
Elbow type, in steel, ground.
Arc’s opening mm 60. Arc’s depth mm 160.
Dimensions
mm
300
500
Section
mm 30x6 30x6
4267L
Each 61,30 62,70
vuoto
FLANGESQUARES
