PUNCHING AND SHEET FOLDING PLIERS
93
2
Prices in EURO - VAT not included
PUNCHING AND SHEET FOLDING PLIERS
431E
Prod. SCU
Body in die-cast aluminium. Hardened forming jaws.
The welding of two metal sheets results in perfectly parallel surfaces. For metal sheets max
thickness 1mm.
FOLDING PLIERS
Pliers type with return spring.
Overall length
mm 220
Jaws width
mm 10
431E
Each 57,40
vuoto
PUNCHINGANDSHEETFOLDINGPLIERS
431G
Prod. SCU - Orig. Tama
Steel body. Hardened forming jaws. Plastic-coated handles.
The welding of two metal sheets results in perfectly parallel surfaces. For metal sheets max
thickness 1mm.
FOLDING PLIERS
Pliers type with double fulcrum and return spring.
Overall length
mm 300
Jaws width
mm 22
431G
Each 73,60
vuoto
PUNCHINGANDSHEETFOLDINGPLIERS
431G 5
Product description as Art. 431G
PUNCHING AND FOLDING PLIERS
Pliers type with return spring.
Revolving head for better positioning while working. With punch Ø 6mm.
Overall length
mm 290
Profiling depth
mm 20
Jaws width
mm 22
Punch max span
mm 7
To punch Ø
mm 4-5-6-7
431G 5
Each 110,00
For spare punches and dies see Art. 432 GT.
PUNCHINGANDSHEETFOLDINGPLIERS
431G 6
Aluminium body. Hardened steel forming jaws.
The welding of 2 metal sheets results in perfectly parallel surfaces.
For metal sheets of maximum thickness 1 mm.
Air compressed patented type, combined for punching metal sheets to be welded
by MIG/TIG system. Revolving head.
With punch Ø 7mm.
Overall length
mm 240
Profiling depth
mm 13
Jaws width
mm 22
Punch max span
mm 7
To punch Ø
mm 4-5-6-7
Use pressure
Atm 6-7
Produced pressure
Kg 850
Weight
Kg
1.4
431G 6
Each 606,00
For spare punches and dies see Art. 432 GT.
Product running out of stock.
PUNCHINGANDSHEETFOLDINGPLIERS
431G 8
Prod. Pneutec - Art. UT 8360
Aluminium body. Hardened steel head. The welding of two metal sheets results in perfectly
parallel surfaces. For metal sheets max thickness 1,4mm.
Air compressed type, combined for punching metal sheets to be welded by MIG/TIG system.
With punch Ø 8mm.
Overall length
mm 240
Air consumption
l/sec 0,5
Noise level
dB 73
Air drive
inches 1/4
To punch Ø
mm 8
Use pressure
Atm 6-7
Weight
Kg
1.3
431G 8
Each 225,00
Spare punch and die Ø 8mm available on request.
PUNCHINGANDSHEETFOLDINGPLIERS
SPARE PARTS FOR PUNCHING MACHINES
432G
Prod. SCU - Orig. Tama
Couples of punches/dies in high-resistance hardened steel. Suitable for indicated punchers.
For punching machines Art. 430 G – 430 G1 – 430 G2.
For bores Ø
mm
2
2,5
3
3,5
4
4,5
5
432G
Per pair 44,50 44,50 44,50 44,50 44,50 44,50 44,50
Body Ø 7mm
