DIGITAL ELECTRONIC DYNAMOMETERS
999
11
Prices in EURO - VAT not included
4487GV
Digital model with remote, very sturdy, heavy duty, with testing and safety requirements according
to the European standard EN 13155/en 61010 and German TÜV-GS standards.
With backlit LCD display, digit 5 (ALT. mm 30 digits), with prolonged reading HOLD weight, press
"0" for a charge balance resets, ON/OFF button to start-up, shut-down.
Operation with internal accumulator, 100 hours, 14 hours charge time approx. 230 V via power
supply included.
Accuracy: ± 0.2% of full scale value.
Supplied with top cricket, inner width 66/73 mm (1000/3000 model) and swivel hook with safety
latch, useful 40 mm Aperture.
Total height with shackle and 610 mm hook. Weight 16 Kg.
Capacity up to
Kg
1000 3000
Division
Kg
0,1
0,5
4487GV
Each 1.440,00 1.490,00
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488
IP20
Digital model with remote control. Aluminium case, extensometer load cell in stainless steel and
indicator with microprocessor. 5-digits LCD display (digits height 25mm) with alarma acoustic
signal for maximum load and discharged batteries. 4 alkalin batteries of 1.5V utonomy: approx. 1
year. Automatic switch-off after 30 minutes. Protection IP20.
Accuracy: ± 0.05% on the full-scale value. Possibility to exclude the tare weight. HOLD function.
Possibility to exclude the tare. Supplied with 2 shackles in forged steel and sturdy plastic case for
easy carrying.
Capacity up to
Kg
3000
6500
9500
Division
Kg
0,2
1
2
4488
Each 1.430,00 1.430,00 1.780,00
For hoist hooks see Art. 2133 Z kg 3200 - 7500 and Art. 2133 ZE kg 3150 - 8000- 12500.
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488B
Digital model for tension and compression measurements, sturdy and user-friendly.
5-digits LCD display (digits height 27mm), ON/OFF key, MAX key for peak measurements, UNIT
key for unit of measure selection (N-Kgf-lbf-oz) and automatic conversion of the values, ZERO key
for measurement reset.
High-frequency data recording (1000 Hz). Uncertainty of measurement ± 0.5% of the max. value.
Overload protection 200% of the peak value. No.6 alkaline batteries 1.5V, rechargeable and 230V
- 50Hz feeder (included). Automatic switch-off.
Supplied with No.6 interchangeable tools (5 heads + 1 extension 90mm).
Weight 0.600kg. Dimensions 195x84x35mm.
In package.
Capacity up to
N
50
100
250
500
1000
Division
N
0,02
0,05
0,1
0,2
0,5
4488B
Each 424,00
424,00
424,00
424,00
424,00
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488E
Digital model for tension and compression measurements, high-precision for high performances.
With data output RS 232.
Backlit LCD display, 5-digit. ON/OFF key, PEAK key for peak measurements, UNIT key for unit of
measure selection (N-Kgf-lbf) and automatic value conversion, ZERO key for measurement reset,
SET key for measuring range verification and remote data transfer, MEMORY key to store up to
10 detected values, PRINT key for data transfer and printing.
High-frequency data recording (2000 Hz). Uncertainty of measurement ± 0.2% of max. value.
Overload protection 150% of max. value. Statistcs function able to generate the average value of
the measured values as well of the max and min load peaks.
Rechargeable battery and 220V - 50Hz feeder (included). Automatic switch-off.
Supplied with No.6 interchangeable tools (5 heads + 1 extension 90mm).
Weight 0.640kg. Dimensions 238x63x36mm.
In case.
Capacity up to
N
5
10
20
50
100
Division
N 0,001
0,005
0,010
0,010
0,050
4488E
Each 801,00
801,00
801,00
801,00
801,00
Capacity up to
N
200
500
Division
N 0,100
0,10
4488E
Each 801,00
801,00
