1051
Prices in EURO - VAT not included
1051
UNIVERSAL STEEL BAR CLAMPS
12
5245GS
Product description as Art. 5245GR
Reinforced model. Throat: 175mm. Bar cross section 40x20mm. Reachable pressure with
150mm opening: approx. 22000 N (2200 kg) equivalent to 80Nm torque value.
Useful opening
mm
300
400
500
600
800
1000 1250
Weight
Kg 5,50
6,10
6,60
7,20
8,30
9,40 10,80
5245GS
Each 116,00 127,00 139,00 150,00 162,00 193,00 223,00
Useful opening
mm
1500
Weight
Kg 12,10
5245GS
Each 250,00
vuoto
UNIVERSALSTEELBARCLAMPS
UNIVERSAL STEEL BAR CLAMPS, QUICK LOCKING
5245GSE
Orig. Kanca
In forged and hardened steel, profiled bar. For rapid locking.
Rack clamping with toothed bar.
Highest strength even in case of vibrations.
Useful opening
mm
160
200
250
300
400
500
600
Depth
mm 80
100
120
140
120
120
120
Rod section
mm 16x7,5 19,5x9,5 22x10,5 25x12 25x12 25x12 25x12
Tightening force
N 2300 3500 4500 5000 5500 5500 5500
5245GSE
Each 31,50 44,80 51,60 63,70 66,90 70,40 73,40
Useful opening
mm
800
1000
Depth
mm 120
120
Rod section
mm 27x13 27x13
Tightening force
N 6000 6000
5245GSE
Each 85,20 94,30
For snap-on clamps see Art. 429 GT-V.
vuoto
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
5245GV
Prod. SCU - Orig. Synchro - Lock
Totally in forged and hardened steel, with profiled bar.
Ratchet-type clamping device, double release (lever and button) for an easier upper and lower
bracketing. Safe location of the device for highest finger protection. Rapid screw clamp closing
and opening with little effort.
Highest tightenig even in case of vibrations.
Useful opening
mm
300
500
600
Depth
mm 120
120
120
Rod section
mm 25x12 25x12 25x12
5245GV
Each 47,60 57,40 59,60
Product running out of stock
vuoto
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
UNIVERSAL IRON BAR CLAMPS
5245GZ
Prod. SCU
Flat rod in hardened steel, side knurled.
Malleable cast iron arms. Wooden handle.
Caps in synthetic material protect clamping surface.
Useful opening
mm
100
150
200
250
300
400
500
Depth
mm 50
50
80
80
80
80
80
Rod section
mm 15x5 15x5 22x6 22x6 22x6 22x6 22x6
5245GZ
Each 8,30
8,48 12,70 13,10 13,60 14,60 15,50
vuoto
UNIVERSAL IRONBARCLAMPS
5246G
Forged and hardened bar, profiled and side knurled for highest strength.
Ribbed arms in high resistance cast iron GTW 40. Wooden handle.
Caps in syntheric material protect work surface.
Type
400L
Useful opening
mm 400
Depth
mm 120
Rod section
mm 29x9
5246G
Each 26,40
Product running out of stock
vuoto
UNIVERSAL IRONBARCLAMPS
