1140
Prices in EURO - VAT not included
1140
SOLID CARBIDE TWIST DRILLS, HIGH-PERFORMANCE, RIGHT-HAND ROTATION
13
8497GP
HARTMETALL
TiAIN
Prod. SCU - Orig. M.D. DRILLS - Art. 13888/89412
Product description as Art. 8497GA
DIN 6537. 140 ° cutting angle.
Lomg model for drilling depths 7 x D.
Forced lubrication through internal cooling channels.
Cylindrical drive.
DIN 6536 HA compliant.
TIALN treatment.
Ø
mm
5
5,5
6
6,5
7
8
8,5
9
10
11
12
13
Overall length
mm 90
97
97
106
116
116
131
131
139
155
163
182
Helix length
mm 50
57
57
66
76
76
87
87
95
106
114
133
Drive Ø
mm 6
6
6
8
8
8
10
10
10
12
12
14
Drive length
mm 36
36
36
36
36
36
40
40
40
45
45
45
8497GP
Each 140,00 140,00 140,00 162,00 162,00 162,00 196,00 196,00 196,00 259,00 259,00 366,00
vuoto
SOLIDCARBIDETWISTDRILLS,HIGH-PERFORMANCE,RIGHT-HANDROTATION
SOLID CARBIDE TWIST DRILLS, K 10/20, HIGH-PERFORMANCE, RIGHT-HAND ROTATION
8499G
HARTMETALL
Orig. Hartner - Art. 89293
Straight discharge TS 150 GG. Cutting angle 120°.
LONG pattern for 10xD drilling depth.
Forced lubrication though internal cooling channels.
Particular sharpening and special web thinning ensure max drilling parameters, precise hole
alignment, minimum diameter tolerances and good finishing of the hole surface. Suitable for high-
precision and high-performance machines. To be used with high-strength precision chucks such
as Centro P orig. FAHRION Art. 1560GH-L-M. For aluminium and aluminium alloys, also with
high silicium content.
Cylindrical shank according to DIN 6535 HA.
Ø
mm
4
4,5
5
5,5
6
6,5
7
8
8,5
9
10
11
12
13
Overall length
mm 121 121 121 121 121 146 146 146 175 175 175 209 209 233
Helix length
mm 77
77
82
82
82 106 106 106 130 130 130 159 159 183
Drive Ø
mm 6
6
6
6
6
8
8
8
10
10
10
12
12
14
Drive length
mm 36
36
36
36
36
36
36
36
40
40
40
45
45
45
8499G
Each 95,30 95,30 95,30 95,30 95,30 125,00 125,00 125,00 158,00 158,00 158,00 196,00 196,00 262,00
vuoto
SOLIDCARBIDETWISTDRILLS,K 10/20,HIGH-PERFORMANCE,RIGHT-HANDROTATION
STUB DRILLS, RIGHT HAND CUTTING
8500G
HSS
Orig. Hartner - Art. 82010
DIN 345. Type N. HSS. Cutting angle 118°.
For steel up to R 900 N/sqmm, cast iron, spheroidal cast iron, aluminium and aluminium alloys,
bronze and brass.
Morse taper shank.
Ø
mm
6 6,25*
6,5 6,75
7 7,25*
7,5
8
8,5 8,75
9 9,25*
9,5 9,75*
10
Overall length
mm 138 144 144 150 150 150 150 156 156 162 162 162 162 168 168
Helix length
mm 57
53
63
69
69
69
69
75
75
81
81
81
81
87
87
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8500G
Each 31,90 49,30 31,50 32,90 31,50 86,10 38,40 27,30 30,10 52,70 29,60 47,20 37,10 71,20 30,10
Ø
mm
10,25 10,5 10,75 11 11,25 11,5 11,75 12 12,25 12,5 12,75 13 13,25 13,5 13,75
Overall length
mm 168 168 175 175 175 175 175 182 182 182 182 182 189 189 189
Helix length
mm 87
87
94
94
94
94
94 101 101 101 101 101 108 108 108
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8500G
Each 52,70 33,30 54,60 32,90 63,80 39,30 50,10 33,80 57,30 35,60 55,50 37,10 55,50 41,60 55,50
Ø
mm
14 14,25 14,5 14,75 15 15,25 15,5 15,75 16 16,25 16,5 16,75 17 17,25 17,5
Overall length
mm 189 212 212 212 212 218 218 218 218 223 223 223 223 228 228
Helix length
mm 108 114 114 114 114 120 120 120 120 125 125 125 125 130 130
Drive
C.M.
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8500G
Each 38,40 66,60 41,20 73,10 43,10 62,90 46,30 63,80 46,30 77,70 50,10 71,20 52,70 75,80 53,60
Ø
mm
17,75 18 18,25 18,5 18,75 19 19,25 19,5 19,75 20 20,25 20,5 20,75 21 21,25
Overall length
mm 228 228 233 233 233 233 238 238 238 238 243 243 243 243 248
Helix length
mm 130 130 135 135 135 135 140 140 140 140 145 145 145 145 150
Drive
C.M.
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8500G
Each 73,10 56,40 84,10 60,10 80,50 60,10 93,40 69,40 90,60 64,70 106,00 68,40 102,00 73,10 110,00
Ø
mm
21,5 21,75 22 22,25 22,5 22,75 23 23,25 23,5 23,75 24 24,5 24,75 25 25,25
Overall length
mm 248 248 248 248 253 253 253 276 276 281 281 281 281 281 286
Helix length
mm 150 150 150 150 155 155 155 155 155 160 160 160 160 160 165
Drive
C.M.
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
8500G
Each 83,20 105,00 80,50 110,00 86,90 110,00 94,30 137,00 93,40 146,00 98,90 102,00 159,00 110,00 160,00
Ø
mm
25,5 25,75 26 26,25 26,5 27 27,25 27,5 27,75 28 28,25 28,5 28,75 29 29,25
Overall length
mm 286 286 286 286 286 291 291 291 291 291 296 296 296 296 296
Helix length
mm 165 165 165 165 165 170 170 170 170 170 175 175 175 175 175
Drive
C.M.
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
8500G
Each 112,00 164,00 125,00 202,00 122,00 125,00 198,00 129,00 215,00 136,00 209,00 170,00 281,00 148,00 272,00
SEGUE >>>
