665
Prices in EURO - VAT not included
665
SPRING PLUNGERS WITH THREADS
9
2812M
Ball nose spring plunger, in special plastic material, with hex socket.
Hardened steel body, 5.8 resistance class, burnished.
Straight slot in the nose in plungers Ø from 4 to 16 is used for installation in blind boringd, through
special fitting key Art. O2812 M Size: 4-16.
Thread D Ø
M.
4
5
6
8
10
12
16
Force min F1
N 5
6
7
9
9
10
45
Max. force F2
N 16
20
20
35
35
55
100
D1 tip Ø
mm 1,5
2,4
2,7
3,5
4
6
7,5
Presser L length
mm 15
18
20
22
22
28
32
Tip extension H
mm 1,5
2,3
2,5
3
3
4
5
Hexagonal size S
mm 1,3
1,5
2
2,5
3
4
5
Weight approx.
grams 0,8
1,3
2,5
6
9
16
35
2812M
Each 3,90
3,70
3,90
4,58
5,44
6,76
8,26
vuoto
Installation wrenches for Art. 2812 L/M.
Size
3
4
5
6
8
10
12
16
For pressers 2812 L Ø mm 3
4
5
6
8
10
12
16
For pressers 2812 M Ø mm -
4
5
6
8
10
12
16
O2812M
Each 45,40 26,20 26,20 26,20 31,70 32,70 36,90 40,30
vuoto
SPRINGPLUNGERSWITHTHREADS
2812P
Ball spring plunger with hex socket. In hardened steel, 5.8 resistance class, burnished.
Hardened ball.
Thread D Ø
M.
6
8
10
12
16
20
24
Force min F1
N 9
15
20
30
65
80
90
Max. force F2
N 13
30
35
55
125
160
180
Ball D1 Ø
mm 3,5
4,5
6
8
10
12
15
Presser L length
mm 15
18
23
26
33
43
48
Ball H extension
mm 1
1,5
2
2,5
3,5
4,5
5,5
Hexagonal size S
mm 3
4
5
6
8
10
12
Weight approx.
grams 2
4
8
12
31
64
100
2812P
Each 2,62
3,28
3,70
4,78
6,30
8,48 14,90
vuoto
SPRINGPLUNGERSWITHTHREADS
2812R
INOX
Ball spring plunger with hex socket. In stainless steel. Hardened ball.
Thread D Ø
M.
6
8
10
12
16
20
24
Force min F1
N 9
15
20
30
65
80
90
Max. force F2
N 13
30
35
55
125
160
180
Ball D1 Ø
mm 3,5
4,5
6
8
10
12
15
Presser L length
mm 15
18
23
26
33
43
48
Ball H extension
mm 1
1,5
2
2,5
3,5
4,5
5,5
Hexagonal size S
mm 3
4
5
6
8
10
12
Weight approx.
grams 2
4
8
12
31
64
100
2812R
Each 6,76
7,40
8,68 11,60 18,10 23,10 36,90
vuoto
SPRINGPLUNGERSWITHTHREADS
2812S
Ball spring plunger with hex socket and heavy end pressure. In hardened steel, 5.8 resistance
class, burnished. Hardened ball.
Thread D Ø
M.
6
8
10
12
16
20
24
Force min F1
N 28
47
66
66
90
115
130
Max. force F2
N 40
73
100
120
180
240
270
Ball D1 Ø
mm 3,5
4,5
6
8
10
12
15
Presser L length
mm 15
18
23
26
33
43
48
Ball H extension
mm 1
1,5
2
2,5
3,5
4,5
5,5
Hexagonal size S
mm 3
4
5
6
8
10
12
Weight approx.
grams 2
4
8
12
31
64
100
2812S
Each 2,86
3,68
3,92
5,44
6,96
9,36 16,40
vuoto
SPRINGPLUNGERSWITHTHREADS
2812T
INOX
Ball spring plunger with hex socket and heavy end pressure. In stainless steel. Hardened ball.
Thread D Ø
M.
6
8
10
12
16
20
24
Force min F1
N 28
47
66
66
90
115
130
Max. force F2
N 40
73
100
120
180
240
270
Ball D1 Ø
mm 3,5
4,5
6
8
10
12
15
Presser L length
mm 15
18
23
26
33
43
48
Ball H extension
mm 1
1,5
2
2,5
3,5
4,5
5,5
Hexagonal size S
mm 3
4
5
6
8
10
12
Weight approx.
grams 2
4
8
12
31
64
100
2812T
Each 7,62
8,26
9,58 12,70 19,90 25,10 41,40
vuoto
