889
Prices in EURO - VAT not included
889
PRECISION INSIDE MICROMETERS
11
PRECISION INSIDE MICROMETERS
3793E
HARTMETALL
1/100
Orig. MIB
Precision according to DIN 863/1.
Reading 1/100 mm.
Contact surfaces in hardmetal. Ratchet screw.
Matt chrome plated thimble.Supplied in case.
Capacity
mm
5-30
25-50
50-75 75-100
Supplier code.....................
01021001 01021002 01021003 01021004
3793E
Each 118,00 134,00 157,00 180,00
Art. 3793 E 5-30 and 25-50 with reference ring.
vuoto
PRECISION INSIDEMICROMETERS
SETS OF PRECISION INSIDE MICROMETERS
3794G
HARTMETALL
Orig. MIB
3-point model, in hardmetal, precision model according to DIN 863, suited to measure through
and blind borings. Reading: 5/1000 mm (6 to 12mm: reading 1/1000). Matt chrome plated
graduated parts. Ratchet screw (pitch 0.5mm), thimble Ø 23mm (6 to 12mm Ø 19mm). Supplied
with calibration key, setting ring and extensions. Supplied in packaging.
Precision of capacity 6 to 40mm: 0,004mm
Precision of capacity 40 to 100mm: 0,005mm
Capacity
mm
6 -12
12-20
20-50 50-100
No. of micrometres
3
2
4
4
Rings Ø
mm 6-8-10
16
25 and 40 62 and 87
Extensions length
mm 100
150
2x150
150
Supplier code.....................
01022070 01022071 01022074 01022075
3794G
Each 1.420,00 783,00 1.890,00 2.360,00
vuoto
SETSOFPRECISION INSIDEMICROMETERS
PRECISION INSIDE MICROMETERS
3794GF
HARTMETALL
5/1000
Orig. MIB
3-point model, in hardmetal, precision model according to DIN 863, suited to measure through
and blind borings. Reading: 5/1000 mm (6 to 12mm: reading 1/1000). Matt chrome plated
graduated parts. Ratchet screw (pitch 0.5mm), thimble Ø 23mm (6 to 12mm Ø 19mm). Supplied
with calibration key and setting rings. Supplied in packaging.
Measuring range from 6 to 40mm: 0.004mm.
Measuring range from 40 to 100mm: 0.005mm.
With extensions for depth measurements.
Capacity
mm
6-8
8-10 10-12 12-16 16-20 20-25 25-30
Measuring depth
mm 55
55
55
81
81
91
91
Extensions length
mm 100
100
100
150
150
150
150
Supplier code ..................
01022077 01022078 01022079 01022080 01022081 01022082 01022083
3794GF
Each 517,00 517,00 517,00 392,00 392,00 517,00 517,00
Capacity
mm
30-40 40-50 50-63 62-75 75-88 87-100
Measuring depth
mm 101
101
115
115
115
115
Extensions length
mm 150
150
150
150
150
150
Supplier code ..................
01022084 01022085 01022086 01022087 01022088 01022089
3794GF
Each 564,00 673,00 705,00 720,00 736,00 783,00
vuoto
PRECISION INSIDEMICROMETERS
3795
1/100
Precision according to DIN 863/1. Reading: 1/100 mm.
Convex contact surfaces, in hardened steel, ground and lapped.
Matt chrome plated finish.
Capacity
mm
25-30
30-35
35-50
50-75 75-100 100-125 125-150
Supplier code ..
01021010 01021011 01021012 01021013 01021014 01021015 01021016
3795
Each 246,00 246,00 246,00 267,00 282,00 313,00 329,00
vuoto
PRECISION INSIDEMICROMETERS
3795F
HARTMETALL
1/100
Orig. MIB - Art. 01021044
Precision according to DIN 863/1. Reading: 1/100 mm. Matt chrome plated thimble Ø 15mm.
Convex contact surfaces in hardmetal. Micrometer measuring range 50 - 63mm. Referance
gauge and extension. Supplied in case.
Set measuring range 50 - 150mm.
Each set consists of No.1 micrometer and No.3 extensions (13 - 25 - 50mm).
3795F
Per series 180,00
vuoto
PRECISION INSIDEMICROMETERS
