HAND RIVETERS
104
2
Prices in EURO - VAT not included
499G
Professional type, 360° revolving head for reaching difficult to access areas.
Sturdy in die-cast aluminium body.
Synthetic material ergonomic handles.
Locking spring and ring. With 4 heads.
For aluminium rivets up to Ø mm. 5
For copper and steel rivets up to Ø mm. 4
Service key.
Overall length
mm 280
Weight
Kg 0,620
499G
Each 63,50
vuoto
HANDRIVETERS
499P
Industrial type.
In die-cast aluminium body sheet steel lever.
Synthetic material ergonomic handles. With 4 heads.
For aluminium, copper, steel, stainless steel rivets up to Ø mm. 4,8
Overall length
mm 335
Weight
Kg 0,840
499P
Each 53,80
vuoto
HANDRIVETERS
500
Long lever type for limited effort and use in difficult to access areas.
In cast aluminium body, sturdy sheet steel levers,
synthetic material ergonomic handles. With 5 heads.
With plastic tray to collect cut-down ends.
For aluminium, copper, steel, stainless steel rivets up to Ø mm. 6,4.
Overall length
mm 530
Weight
Kg 1,810
500
Each 78,70
vuoto
HANDRIVETERS
501
new
With a single rotating head for rivets of four measures: 3.2-4-4.8/5-6.4 mm. Advantages: there is
no need to replace the heads depending on the measurement of the rivet and this prevents the
heads from getting lost.
With long levers for limited effort and for use in places that are hard to reach. Aluminium cast body
and steel lever.
Ergonomic handles made of rubbery material.
With plastic container to collect fragments.
For aluminium, copper, steel, stainless steel rivets up to Ø 6.4 mm.
Overall length
mm 400
Weight
Kg 2,000
501
Each 63,40
vuoto
HANDRIVETERS
502A
Pantograph type for one-hand use.
Die-cast aluminium head and handle. With four heads.
Max extension 320 to 850mm.
For aluminium, copper, steel, stainless steel rivets up to Ø mm. 6,4.
Weight
Kg 1,660
502A
Each 141,00
vuoto
HANDRIVETERS
AIR RIVETERS
504G
Prod. Pneutec - Art. UT4DPP
Oleo-pneumatic type, light and handy for maintenance works.
Light alloy body, steel operating parts.
Air attachment R 1/4. Use pressure 6,3 Atm. With plastic tray to collect cut-down ends.
Only for aluminium and copper rivets up to Ø mm. 4,8
Length
mm 260
Air consumption
l/sec 1,2
Noise level
dB 77,5
Vibrations
m/sec² < 2,5
Weight
Kg 1,500
504G
Each 243,00
vuoto
AIRRIVETERS
