HYDROPNEUMATIC-RIVETERS FOR THREADED RIVETS
109
2
Prices in EURO - VAT not included
514H
Product description as Art. 514G
For aluminium and steel threaded rivets Ø M 4-5-6-8-10-12.
For STAINLESS steel threaded rivets Ø M 4-5-6-8-10.
Length
mm 330
Weight
Kg 2,500
514H
Each 2.440,00
Spare stay bolts on request.
vuoto
HYDROPNEUMATIC-RIVETERSFOR THREADEDRIVETS
514L
new
Hydro-pneumatic tool with great power and durability.
Light alloy body, covered with insulating material.
Air connection with plug for rapid taps and 9 mm hose (see Art. 3480 GD). Operating pressure 5-
7 ATM. With 7 rods complete with bolts and threaded nuts.
For threaded aluminium, steel and stainless steel inserts Ø M 3-4-5-6-8-10-12.
Length
mm 285
Weight
Kg 1,600
514L
Each 1.950,00
vuoto
HYDROPNEUMATIC-RIVETERSFOR THREADEDRIVETS
ALUMINIUM THREADED RIVETS
514P
Prod. SCU
FLAT head.
In aluminium.
Packing: 200 pcs
Thread (F)
M
3
4
5
6
6A
8
10
Bore Ø
mm 5
6
7
9
9
11
12
Thickness (S)
mm 0,3-1,8 0,3-2,5 0,5-3 0,5-2,3 2,3-4 0,8-3,5 1-3,5
Ext. Ø (d)
mm 4,9
5,9
6,9
8,9
8,9
10,9 11,9
Ø with edge (D)
mm 8
9
10
12
12
15
16
Edge thickness (H)
mm 0,8
1
1,2
1,5
1,5
1,5
1,7
Overall length (L)
mm 9
11
13
14,5
16
17,5
19
514P
Per pack 21,50 15,30 16,50 21,20 34,40 26,20 57,60
vuoto
ALUMINIUMTHREADEDRIVETS
STEEL THREADED RIVETS
514R
Prod. SCU
FLAT head.
In steel.
Packing: 200 pcs, only the size 12 with pack 100 pcs.
Thread (F)
M
3
4
5
6
6A 8
10
12
Bore Ø
mm 5
6
7
9
9
11
12
16
Thickness (S)
mm 0,3-
1,8
0,3-
2,5
0,5-3 0,5-
2,3
2,3-4 0,8-
3,5
1-3,5 1-3,5
Ext. Ø (d)
mm 4,9 5,9 6,9 8,9 8,9 10,9 11,9 15,9
Ø with edge (D)
mm 8
9
10
12
12
15
16
22
Edge thickness (H)
mm 0,8
1
1,2 1,5 1,5 1,5 1,7 1,9
Overall length (L)
mm 9
11
13 14,5 16 17,5 19
25
514R
Per pack 12,20 13,90 14,80 17,40 19,10 21,70 33,90 58,90
When stocks are depleted, we will provide only the sizr M12 with knurling.
vuoto
STEELTHREADEDRIVETS
514T
WIRE REDUCED head.
In steel.
Packing: 200 pcs
Thread (F)
M
3
4
5
6
8
10
Bore Ø
mm 5
6
7
9
11
12
Thickness (S)
mm 0,5-1,5 0,5-1,5 0,5-2 0,5-2 1-2,5 1-2,5
Ext. Ø (d)
mm 4,9
5,9
6,9
8,9
10,9
11,9
Ø with edge (D)
mm 5,5
6,7
8
10
12
13,5
Overall length (L)
mm 8,5
10
12
13,5
16,5
18
514T
Per pack 12,20 13,90 14,80 17,40 21,70 33,90
