1045 / 1378
1045
UNIVERSAL STEEL BAR CLAMPS, QUICK LOCKING
1045
12
Prices in EURO - VAT not included
UNIVERSAL STEEL BAR CLAMPS, QUICK LOCKING
5245GSE
Orig. Kanca
In forged and hardened steel, profiled bar. For rapid locking.
Rack clamping with toothed bar.
Highest strength even in case of vibrations.
Useful opening
mm
160
200
250
300
400
500
600
Depth
mm 80
100
120
140
120
120
120
Rod section
mm 16x7,5 19,5x9,5 22x10,5 25x12 25x12 25x12 25x12
Tightening force
N 2300 3500 4500 5000 5500 5500 5500
5245GSE
Each 31,10 44,10 50,80 62,80 65,90 69,40 72,30
Useful opening
mm
800
1000
Depth
mm 120
120
Rod section
mm 27x13 27x13
Tightening force
N 6000 6000
5245GSE
Each 83,90 92,90
For snap-on clamps see Art. 429 GT-V.
vuoto
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
5245GT
Orig. Gedore - Art. TGE
Product description as Art. 5245GSE
Useful opening
mm
160
600
800
1000
Depth
mm 80
120
120
120
Rod section
mm 16x8 25x12 28x14 28x14
Tightening force
N 2300 5500 6000 6000
5245GT
Each 61,70 113,00 126,00 135,00
Product running out of stock.
vuoto
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
5245GV
Prod. SCU - Orig. Synchro - Lock
Totally in forged and hardened steel, with profiled bar.
Ratchet-type clamping device, double release (lever and button) for an easier upper and lower
bracketing. Safe location of the device for highest finger protection. Rapid screw clamp closing
and opening with little effort.
Highest tightenig even in case of vibrations.
Useful opening
mm
250
300
400
500
600
Depth
mm 120
120
120
120
120
Rod section
mm 25x12 25x12 25x12 25x12 25x12
5245GV
Each 42,90 47,60 53,30 57,40 59,60
Product running out of stock.
vuoto
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
5245GVE
Prod. SCU
With Ø 12 mm hole on the support base for mounting on the work surface.
Made of forged and hardened steel, with profiled bar. For quick locking
Tightening mechanism with rack and gear lever. Maximum durability also in the presence of
vibration.
Useful opening
mm 200
Depth
mm 100
Rod section
mm 21x10
Tightening force
N 3500
5245GVE
Each 237,00
vuoto
Product running out of stock.
UNIVERSALSTEELBARCLAMPS,QUICK LOCKING
UNIVERSAL IRON BAR CLAMPS
5245GZ
Prod. SCU
Flat rod in hardened steel, side knurled.
Malleable cast iron arms. Wooden handle.
Caps in synthetic material protect clamping surface.
Useful opening
mm
100
150
200
250
300
400
500
Depth
mm 50
50
80
80
80
80
80
Rod section
mm 15x5 15x5 22x6 22x6 22x6 22x6 22x6
5245GZ
Each 8,02
8,18 12,20 12,70 13,20 14,10 15,10
vuoto
UNIVERSAL IRONBARCLAMPS
