UNIVERSAL IRON BAR CLAMPS
1047
12
Prices in EURO - VAT not included
5246GF
According to DIN 5117.
Forged and hardened bar, profiled and side knurled for highest strength.
High resistance cast iron arms. With sliding bar handle.
Caps in syntheric material protect work surface.
Useful opening
mm
160
200
250
300
400
500
600
Depth
mm 80
100
120
140
120
120
120
Rod section
mm 22x6 30x8 30x8 35x9 35x11 35x11 35x11
Tightening force
N 5000 5000 5000 5000 7500 7500 7500
5246GF
Each 28,10 39,10 47,30 59,20 64,90 72,30 74,40
Useful opening
mm
800
1000 1250 1500 2000
Depth
mm 120
120
120
120
120
Rod section
mm 35x11 35x11 35x11 35x11 35x11
Tightening force
N 7500 7500 7500 7500 7500
5246GF
Each 83,40 96,20 101,00 115,00 140,00
vuoto
UNIVERSAL IRONBARCLAMPS
5246GL
Flat rod, large cross section bar, forged and hardened steel, side knurled for highest strength.
Ribbed arms in high resistance cast iron.
With sliding bar handle.
Type
400 400A 600 600A 800 800A 1000
Useful opening
mm 400
400
600
600
800
800
1000
Depth
mm 250
400
250
400
300
400
300
Rod section
mm 45x12 45x12 45x12 45x12 45x12 45x12 45x12
Tightening force
N 8000 8000 8000 8000 8000 8000 8000
5246GL
Each 82,90 143,00 93,80 155,00 117,00 166,00 129,00
Type
1000A
Useful opening
mm 1000
Depth
mm 400
Rod section
mm 45x12
Tightening force
N 8000
5246GL
Each 182,00
vuoto
UNIVERSAL IRONBARCLAMPS
5246GM
Forged and hardened bar, side knurled for highest strength.
Ribbed arms in high resistance cast iron GTW 40. Slider grip.
Caps in syntheric material protect work surface.
Throat: 140mm. Bar cross section: 32x10mm.
Useful opening
mm
600
800
1000
5246GM
Each 41,70 47,10 52,60
Product running out of stock.
vuoto
UNIVERSAL IRONBARCLAMPS
U-STEEL BAR CLAMPS
5249GE
Prod. SCU
Suitable to tighten bulky workpieces. Slider grip. In forged and hardened steel, profiled bar. Quick
adjusting tightening device with clamp and mobile, reinforced and interchangeable clamping
surface. Totally galvanized, burnished clamp screws.
Particularly suitable for carpentry, welding, building, etc.
Useful opening
mm
250
Depth
mm 120
Rod section
mm 22x11
5249GE
Each 62,10
Product running out of stock.
