HSS TAPS AND DIES
1243
13
Prices in EURO - VAT not included
9403GF
BSF
HSS
HSS HAND TAPS. RIGHT-HAND USE.
Thread: BSF Whitworth Pitch. DIN 2181. Tolerance H6.
Set: 2 pcs.
For threads
inches
3/16
5/16
3/8
1/2
5/8
3/4
1
Threads per inch
No
32
22
20
16
14
12
10
9403GF
Per set 23,30 27,90 32,50 44,30 60,60 81,40 135,00
For similar hand tap sets see Art. 9120 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9404GC
UNC
HSS
HAND TAPS – HSS steel. RIGHT-HAND USE.
UNC American Thread. DIN 352-ANSI-B1-1. Tolerance H6.
3pcs set.
Thread UNC
No. 6 No. 8 No. 10 No. 12 5/16
7/16
9/16
Threads per inch
No
32
32
24
24
18
14
12
9404GC
Per set 34,90 34,90 38,30 38,30 41,80 51,70 82,50
For similar hand tap sets see Art. 9125 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9404GF
UNF
HSS
HAND TAPS – HSS steel. RIGHT-HAND USE.
UNF American Thread. DIN 2181-ANSI-B1-1. Tolerance H6.
2pcs set.
Thread UNF
No. 6 No. 8 No. 10 No. 12
Threads per inch
No
40
36
32
28
9404GF
Per set 30,20 30,20 30,20 30,20
For similar hand tap sets see Art. 9130 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9404GR
NPT
HSS
SHORT HAND/MACHINE TAPS. Made from HSS steel. RIGHT-HAND USE.
NPT American conical thread, taper 1:16. ANSI-B2.1.
For threads
inches
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
No
27
18
18
14
14
11,5
11,5
Overall length
mm 54
62
65
79
83
95
102
Thread length
mm 19
27
27
35
35
44
44
9404GR
Each 39,20 43,50 56,20 74,50 102,00 153,00 266,00
vuoto
HSSTAPSANDDIES
9404GS
BSPT
HSS
SHORT HAND/MACHINE TAPS. Made from HSS steel. RIGHT-HAND USE.
BSPT conical gas thread, taper 1:16.
For threads
inches
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
No
28
19
19
14
14
11
11
Overall length
mm 59
67
75
87
96
109
119
Thread length
mm 15
19
21
26
28
33
36
9404GS
Each 47,60 54,30 65,90 85,20 116,00 167,00 269,00
vuoto
HSSTAPSANDDIES
9405GA
M
HSS
HSS MACHINE TAPS. RIGHT-HAND USE.
Reinforced shank, correct chamfer for through holes.
M Coarse Metric Thread. DIN 371 B. Tolerance H6.
For threads
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
9405GA
Each 7,92
7,92
7,92
8,44
9,66 11,50
