1248 / 1378
1248
HSS TAPS AND DIES
1248
13
Prices in EURO - VAT not included
9406GD
M
HSS
HSS ROUND DIES. LEFT-HAND USE.
M Coarse Metric Thread. DIN 223. 6g tolerance.
For threads
mm
3
18
Pitch
mm 0,5
2,5
Dimensions
mm 20x5 45x18
9406GD
Each 17,60 39,70
For similar screw dies see Art. 9353 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9406GF
MF
HSS
HSS ROUND DIES. RIGHT-HAND USE.
MF Fine Metric Thread. DIN 223. 6g tolerance.
For threads
mm
4
5
6
8
8
10
10
12
Pitch
mm
0,5
0,5 0,75 0,75
1
1
1,25
1
Dimensions
mm 20x5 20x5 20x7 25x9 25x9 30x11 30x11 38x10
9406GF
Each 9,56 9,56 9,56 9,84 9,84 11,40 11,40 16,20
For threads
mm
12
12
14
14
14
16
16
18
Pitch
mm
1,25 1,5
1
1,25 1,5
1
1,5
1,5
Dimensions
mm 38x10 38x10 38x10 38x10 38x10 45x14 45x14 45x14
9406GF
Each 16,20 16,20 17,40 17,40 17,40 24,40 24,40 24,80
For threads
mm
20
22
24
24
27
30
Pitch
mm
1,5
1,5
1,5
2
2
2
Dimensions
mm 45x14 55x16 55x16 55x16 65x18 65x18
9406GF
Each 25,80 35,80 40,30 40,30 50,50 53,70
vuoto
HSSTAPSANDDIES
9406GL
BSW
HSS
Product description as Art. 9406GF
Whitworth Thread. DIN 223. 6g tolerance.
For threads
inches
3/16
5/8
1
Threads per inch
No
24
11
8
Dimensions
mm 20x7 45x18 55x22
9406GL
Each 13,80 29,70 51,40
For similar screw dies see Art. 9360 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9406GM
BSF
HSS
Product description as Art. 9406GF
Thread: BSF Fine Whitworth pitch. DIN 223.
Tolerance 6g.
For threads
inches
5/8
3/4
1
Threads per inch
No
14
12
10
Dimensions
mm 45x14 45x14 55x20
9406GM
Each 91,60 95,40 136,00
For similar screw dies see Art. 9362 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9406GP
GAS
HSS
Product description as Art. 9406GF
Cylindrical GAS Thread for threading pipes. DIN 5158. 6g tolerance.
For threads
inches
1.1/4
Threads per inch
No
11
Dimensions
mm 75x20
9406GP
Each 111,00
For similar screw dies see Art. 9368 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
9406GS
UNC
HSS
Product description as Art. 9406GF
UNC American Thread. DIN 223. 6g tolerance.
Thread UNC
9/16
5/8
7/8
1
Threads per inch
No
12
11
9
8
Dimensions
mm 38x14 45x18 55x22 55x22
9406GS
Each 52,70 64,90 90,60 92,10
For similar screw dies see Art. 9364 G.
Product running out of stock.
vuoto
HSSTAPSANDDIES
