GROUND AND TREATED BARS
1275
13
Prices in EURO - VAT not included
9690
HSS-E
Product description as Art. 9688
TRAPEZOIDAL. Tolerance h 12 – DIN 4964E.
Dimensions
mm
3x12x160 3x20x200 4x16x160 4x20x200 5x20x160
9690
Each 16,10
41,80
29,90
43,80
41,80
Dimensions
mm
5x20x200 5x25x200 6x25x200
9690
Each 51,70
93,10
87,50
Size mm 5x25x200 running out of stock.
vuoto
GROUNDAND TREATEDBARS
9691
HSS-E
Product description as Art. 9688
ROUND. Tolerance h 8 – DIN 4964A.
Dimensions
mm
2x40 3x63 4x63 4x80 4x100 5x63 5x80
9691
Each 6,16
4,18
4,58
5,08
5,96
4,58
6,56
Dimensions
mm
5x100 6x63 6x80 6x100 6x160 6x200 8x63
9691
Each 6,56
5,96
6,56
7,56 11,40 14,60 7,16
Dimensions
mm
8x80 8x100 8x160 8x200 10x80 10x100 10x160
9691
Each 8,56
9,74 15,80 19,10 11,10 12,70 18,50
Dimensions
mm
10x200 12x125 12x160 12x200 14x125 14x160 14x200
9691
Each 23,50 21,10 25,70 30,90 25,90 33,80 43,80
Dimensions
mm
16x125 16x160 16x200 18x200 20x160 20x200
9691
Each 33,60 42,80 52,10 59,70 58,70 73,60
vuoto
GROUNDAND TREATEDBARS
TURNING TOOL HOLDERS
9708G
Orig. Hufnagel
Treated steel body. Heavy execution. Patented locking system.
HSS-E Cobalt 10% bars, square section, hardened and ground.
"Orkan-S" quality (W 9% - Co 10% - Mo 3.5).
Straight tool holder with bar.
Size K
6
8
12
Iron rest overall length
mm 125
165
240
Iron rest section
mm 18x12 25x17 35x25
Bar dimensions
mm 6x63 8x100 12x125
Height from base to cutting edge mm 15
20
29
9708G
Each 228,00 299,00 475,00
Product running out of stock.
vuoto
TURNINGTOOLHOLDERS
9710G
HSS-E
“Orkan-S" bars, hardness HRC 65-67. For Art. 9708 G.
Size K
6
8
10
12
Bar dimensions
mm 6x63 8x100 10x100 12x125
9710G
Each 18,20 25,10 28,80 45,10
Product running out of stock.
vuoto
TURNINGTOOLHOLDERS
CUTTING TOOL HOLDERS
9713G
Orig. Hufnagel
Treated steel body.
Safe locking system.
HSS-E bars, trapezoidal section, hardened and ground.
"Orkan-S" quality (W 12% - Co 5% - Va 4%).
Tool holder with bar.
Size D
4
Bar dimensions
mm 160x18x5
Height from base to cutting edge mm 27
Blades holder overall length
mm 160
Blades sections
mm 40x20
9713G
Each 292,00
Product running out of stock.
vuoto
CUTTINGTOOLHOLDERS
9714G
HSS
“Orkan-S" bars, hardness HRC 66. For Art. 9713 G.
Size D
2
3
Bar dimensions
mm 100x10x2,5 150x15x4
9714G
Each 36,60
57,50
Product running out of stock.
vuoto
