TOOL HOLDERS AND BARS FOR INSIDE USE
1277
13
Prices in EURO - VAT not included
9725G
HSS-E
Product description as Art. 9721G
Bars for slots.
Size BN
7
13
16
Overall length
mm 65
75
100
Drive length
mm 35
42
78
Drive Ø
mm 8
10
10
For bore by Ø min
mm 7
13
16
Cutting edge thickness
mm 1,5
2,5
3
9725G
Each 52,50 73,30 98,20
Product running out of stock.
TOOLHOLDERSANDBARSFOR INSIDEUSE
TOOL HOLDERS FOR INSIDE USE
9728G
Orig. Hufnagel
For internal turning and threading.
Treated steel body.
Ground hardened shank.
Ground and hardened blades, HSS-E Cobalt 10%.
"Orkan-S" quality (W 9% - Co 10% - Mo 3.5). Hardness HRC 65-67.
Also HARD METAL blades, universal quality.
Tool holder without shank and without blades.
Size PB
12
15
20
28
Iron rest overall length
mm 110
130
150
180
Iron rest section
mm 24x20
31x28
37x32
53x50
Stem length and Ø
mm 200x12
250x15
300x20
500x28
For bore by Ø min
mm 16
22
29
38
Blades length
mm 15
20
26
36
Height from base to cutting edge mm 13,5/15,5 16,5/20,5
21/24
30/33
9728G
Each 78,40
81,50
132,00
204,00
Product running out of stock.
TOOLHOLDERSFOR INSIDEUSE
9729G
Product description as Art. 9728G
Straight shank without blades for Art. 9728 G.
Size PB
12
20
28
Iron rest overall length
mm 110
150
180
Iron rest section
mm 24x20
37x32
53x50
Stem length and Ø
mm 200x12
300x20
500x28
For bore by Ø min
mm 16
29
38
Blades length
mm 15
26
36
Height from base to cutting edge mm 13,5/15,5
21/24
30/33
9729G
Each 68,70
123,00
194,00
Product running out of stock.
TOOLHOLDERSFOR INSIDEUSE
9730G
Product description as Art. 9728G
Oblique shank without blades for Art. 9728 G.
Size PB
15
28
Iron rest overall length
mm 130
180
Iron rest section
mm 31x28
53x50
Stem length and Ø
mm 250x15
500x28
For bore by Ø min
mm 22
38
Blades length
mm 20
36
Height from base to cutting edge mm 16,5/20,5
30/33
9730G
Each 82,90
194,00
Product running out of stock.
TOOLHOLDERSFOR INSIDEUSE
9731G
HSS-E
Product description as Art. 9728G
HSS blades for turning for Art. 9729 G and 9730 G.
Size PB
12
15
20
28
Blades length
mm 15
20
26
36
9731G
Each 15,80 18,30 27,80 41,80
Product running out of stock.
TOOLHOLDERSFOR INSIDEUSE
9732G
55
HSS-E
Product description as Art. 9728G
HSS-E blades for 55° Whitworth thread, for Art. 9729 G and 9730 G.
Size PB
12
15
20
28
Blades length
mm 15
20
26
36
9732G
Each 15,80 18,30 27,80 41,80
Product running out of stock.
TOOLHOLDERSFOR INSIDEUSE
9733G
60
HSS-E
Product description as Art. 9728G
HSS-E blades for 60° Metric thread, for Art. 9729 G and 9730 G.
Size PB
12
15
20
28
Blades length
mm 15
20
26
36
9733G
Each 15,80 18,30 27,80 41,80
Product running out of stock.
