ELECTRONIC TORQUE WRENCH TESTERS
180
3
Prices in EURO - VAT not included
793GT
Orig. Gedore
Charge cell electronic device for the measurement of the turning moment. Sturdy aluminium alloy
body. Used for checking torque wrenches with RIGHT+LEFT rotation according to DIN EN ISO
6789. Positionable both horizontally and vertically. The large-easy reading display may be
positioned directly in the device body (except for Art. 793 GT 15) or separately, by means of a
provided support and cable, in the operator’s most visible point.
Precision:± 1% for each scale value, ± 1 digit.
Reading commutation Nm, cNm, lbf-ft, lbf-in.
Provided with certification in compliance with the main national samples. External feeder 12/240
V.
Use temperature from + 10 C° to + 40 C°.
Fastening to benchwork or for wall mounting. Dimensions mm 245x155x150h.
Weight 7Kg (793 GT 15 mm 120x80x80h weight 1.5Kg).
In sturdy box.
Size
15
100
500
1000
Effective load capacity
Nm 0,5-15
4-100
20-500
50-1000
Scale division
0,01 Nm
0,01 Nm
0,1 Nm
0,1 Nm
Square drive
inches
1/4
1/2
3/4
3/4
Reductions
inches
-
1/4 e 3/8
3/8 e 1/2
3/8 e 1/2
Supplier code
8624-B01
8624-B10
8624-B50
8624-B100
793GT
Each 5.500,00
5.500,00
5.500,00
5.500,00
Art. 793 GT 15 is equipped with a friction safety device against surcharge. In case of block, use
wrench Art. O793 GT 15, included.
vuoto
“T" wrenches with square drive 1/4" for device release Art. 793 GT 15.
O793GT 15
Each
26,90
vuoto
ELECTRONICTORQUEWRENCHTESTERS
DIGITAL DYNAMOMETER DEVICES
794A
Prod. SCU
Practical and light model which can be inserted in between the ratchet lever and its socket so that it
can detect the level of tightening being carried out.
Body made from reinforced synthetic material, functional parts made from steel. Precision ± 2%.
Memory capacity for 50 relevant items, display resolution 0.1, selectable units: kg/cm - kg/m - lb/in
- lb/ft - N/m.
Batter power mod. CR 2032 (Art. SCU 3600 T), battery not included. Sleep function. Peaking /
tracking operating modes.
Female/ male square drive
inches
1/2
Tightening capacity
Nm 40-200
Dimensions
mm 75x44
Weight
grams
120
794A
Each
89,70
vuoto
Product running out of stock.
DIGITALDYNAMOMETERDEVICES
PRECISION TORQUE WRENCHES
794G 5
Orig. Gedore - Art. 753-11
Click type. In synthetic material, resistant to fats, oils and hydrocarbons by-products.
Precise adjustment through handle grip ring nut.
Double scale graduation with readings in Nm, lbf. in. Audible acustic signal ("click") on reaching
preset torque value.
Clockwise tightening. Supplied with test certificate in accordance with DIN ISO 6789.
Supplied in box.
Male square drive
inches
1/4
Tightening capacity
Nm 2-12
Tightening capacity
lbf.in
18-106
Scale division
0,5 Nm/5 lbf.in
Overall length
mm 210
Weight
Kg
0,250
794G 5
Each 429,00
vuoto
PRECISION TORQUEWRENCHES
