PRECISION TORQUE WRENCHES
181
3
Prices in EURO - VAT not included
794G 8
Orig. Gedore - Art. 753-03/13
ASSORTED SETS OF TOOLS WITH TORQUE WRENCH
The set contains:
1 x Art. 794G 5 torque wrench 1/4 drive
8 x 4-5-5.5-6-7-8-9-10mm hexagonal sockets
1 x screwdriver handle 1/4 drive
4 x 3-4-5-6mm hexagonal tip sockets
3 x 4-5.5-6.5 flat tip sockets
3 PHILLIPS sockets size 1-2-3
3 x 20-27-30 TORX T. sockets
2 x 55-100mm extensions
1 x ratchet mechanism 1/4 drive
Supplied in case.
794G 8
Each 817,00
vuoto
PRECISIONTORQUEWRENCHES
TORQUE SCREWDRIVERS WITH FIXED TORQUE VALUE
794G 8E
new
Prod. SCU - Orig. Wiha
Types supplied already pre-set (without scale), with torque values recommended by the
manufacturers of tools with mechanical fastening plates (from 0.5 Nm to 5 Nm, with a tolerance of
± 10%). Once the pre-set torque value has been reached, you will hear a click sound, also
detectable by touch. Protected unscrewing function. Ergonomic handles made of multi-
component material to be used with 4 mm hexagonal blades in different shapes Art. 794 G 8F-G-
H-L-M-P-R, with bit-holder Art.794G 8T and socket-holders Art. 794 G 8V.
Handle length 130 mm. For right-hand use.
DYNAMOMETRIC HANDLES WITHOUT BLADES
Tightening value
Nm
0,5
0,6
0,9
1,1
1,2
1,4
2
794G 8E
Each 58,40 58,40 58,40 58,40 58,40 58,40 61,60
Tightening value
Nm
2,5
3
3,8
4
4,5
5
794G 8E
Each 61,60 61,60 61,60 64,90 64,90 64,90
When choosing blades, the maximum torque of the same should be considered.
TORQUESCREWDRIVERSWITHFIXED TORQUEVALUE
794G 8F
new
Made with CHROME-VANADIUM-MOLYBDENUM steel, hardened, matt chrome. Chrom Top® tip
for maximum precision. Blade length 175mm.
BLADES FOR DYNAMOMETRIC HANDLES 794 G 8E
With TORX tip. Colour code: DARK GREEN:
TORX size
T
5
6
7
8
9
10 15 20 25
For screws
M.
1,6 2-2,2 2,5 2,5-2,9 3 3-3,5 3,5-4 4-5 4,5-5
Max torque
Nm 0,4 0,6 0,9 1,3 2,5 3,8 5,5 8,0 8,0
794G 8F
Each 7,94 7,94 7,94 7,94 7,94 7,94 7,94 7,94 7,94
In the selection of dynamometric handgrips you need to choose a torque equal to or less than the one max. of the blades.
TORQUESCREWDRIVERSWITHFIXED TORQUEVALUE
794G 8G
new
-PLUS
Product description as Art. 794G 8F
With TORX-PLUS® tip. Colour code: LIGHT GREEN.
TORX-PLUS size
IP
5
6
7
8
9
10 15 20 25
For screws
M.
1,6 2-2,2 2,5 2,5-2,9 3 3-3,5 3,5-4 4-5 4,5-5
Max torque
Nm 0,5 0,8 1,3 2,0 3,0 4,5 6,6 8,0 8,0
794G 8G
Each 8,10 8,10 8,10 8,10 8,10 8,10 8,10 8,10 8,10
In the selection of dynamometric handgrips you need to choose a torque equal to or less than the one max. of the blades.
TORQUESCREWDRIVERSWITHFIXED TORQUEVALUE
794G 8H
new
Product description as Art. 794G 8F
With flat tip. Colour code: GREY
Size
2
2,5
3
3,5
4
Cutting edge
mm 2x0,4 2,5x0,4 3x0,5 3,5x0,6 4x0,8
Max torque
Nm 0,4
0,4
0,6
1,1
2,5
794G 8H
Each 7,78
7,78
7,78
7,78
7,78
In the selection of dynamometric handgrips you need to choose a torque equal to or less than the one max. of the blades.
TORQUESCREWDRIVERSWITHFIXED TORQUEVALUE
794G 8L
new
Product description as Art. 794G 8F
With PHILLIPS tip. Colour code: BLUE.
Size
000
00
0
1
2
For screws
M.
-
-
1,6-2
2-3
3,5-5
Max torque
Nm 0,4
0,4
0,9
3,8
5,5
794G 8L
Each 7,78
7,78
7,78
7,78
7,78
In the selection of dynamometric handgrips you need to choose a torque equal to or less than the one max. of the blades.
