WRENCHES FOR METAL RINGS
221
3
Prices in EURO - VAT not included
842T
Product description as Art. 842R
For KM ring nuts, external toothing.
Locking ring nuts Ø
mm
18
22
25
28
32
38
45
Ø ring nuts thread
mm 10x0,75 12x1 15x1 17x1 20x1 25x1,5 30x1,5
Teeth
Nr
4
4
4
4
4
4
4
Square drive
inches 3/8
3/8
1/2
1/2
1/2
3/4
3/4
842T
Each 34,70 35,70 36,70 38,60 42,40 43,40 44,40
Locking ring nuts Ø
mm
52
58
65
70
75
80
Ø ring nuts thread
mm 35x1,5 40x1,5 45x1,5 50x1,5 55x2 60x2
Teeth
Nr
4
4
4
4
4
4
Square drive
inches 3/4
3/4
3/4
3/4
3/4
3/4
842T
Each 45,40 47,30 51,10 55,90 72,50 84,90
vuoto
WRENCHESFORMETALRINGS
842V
Product description as Art. 842R
For GU self-locking ring nuts, external toothing
Locking ring nuts Ø
mm
18
22
25
28
32
38
44
Ø ring nuts thread
mm 10x0,75 12x1 15x1 17x1 20x1 25x1,5 30x1,5
Teeth
Nr
4
4
4
4
4
4
4
Square drive
inches 3/8
3/8
1/2
1/2
1/2
3/4
3/4
842V
Each 34,70 35,70 36,70 38,60 42,40 43,40 44,40
Locking ring nuts Ø
mm
50
56
62
68
Ø ring nuts thread
mm 35x1,5 40x1,5 45x1,5 50x1,5
Teeth
Nr
4
4
4
4
Square drive
inches 3/4
3/4
3/4
3/4
842V
Each 45,40 47,30 51,10 55,90
vuoto
WRENCHESFORMETALRINGS
BIHEXAGON RING SLOPPING SPANNERS
843G
843GP
Orig. Gedore - Art. 306
In forged CHROME VANADIUM steel up to a length of 435mm, in forged SPECIAL STEEL from a
length of 450mm. Single ended, bihexagonal. Grey sandblasted finish.
Heavy duty. For use with hammers or sledge hammers. Dimensions according to DIN 7444.
Opening
mm
22
24
27
30
32
34
36
38
41
46
50
55
60
65
Overall length
mm 160 160 180 190 195 195 205 205 225 240 250 270 270 290
Head thickness
mm 15
15
15,5 16,5 16,5 16,5 19,5 19,5 20,5 22,5 23,5
25
26
29
Weight
Kg 0,250 0,250 0,350 0,400 0,450 0,600 0,750 0,660 0,850 1,050 1,250 1,550 1,650 2,300
843G
Each 27,70 24,40 29,90 35,10 37,60 39,80 46,50 50,30 60,80 65,30 75,70 83,90 90,30 119,00
Opening
mm
70
75
80
85
90
95
100 105 110 115 120 125 130 135
Overall length
mm 320 325 345 360 400 400 400 435 435 435 480 480 520 520
Head thickness
mm 32,5
34
35
37
41,5 41,5 41,5 47,5 47,5 47,5
54
54
58
58
Weight
Kg 2,600 3,350 3,800 4,200 5,700 5,700 5,700 8,500 8,500 8,500 10,000 10,000 13,000 13,000
843G
Each 131,00 142,00 201,00 244,00 294,00 332,00 372,00 467,00 504,00 547,00 1.220,00 1.560,00 1.690,00 1.780,00
Opening
mm
140 145 150 155 160 165 170 175 185 190 195 210
Overall length
mm 520 580 580 580 580 650 650 650 700 700 700 750
Head thickness
mm 58
64
64
64
64
70
70
70
75
75
75
80
Weight
Kg 13,000 18,000 18,000 18,000 18,000 25,000 25,000 25,000 32,000 32,000 32,000 40,000
843G
Each 2.050,00 2.680,00 2.920,00 3.140,00 3.140,00 3.360,00 4.070,00 4.480,00
on request
vuoto
When stocks are depleted, the size 22 mm will become SCU. Sizes 24 to 60 mm are supplied with UNIT DRIVE shaped opening.
Size mm 170 running out of stock.
Product description as Art. 843G
MODEL WITH OPENINGS IN US INCH SIZES
Opening
inches
1 1.1/16 1.1/8 1.3/16 1.1/4 1.5/16 1.3/8 1.7/16 1.1/2 1.5/8 1.11/16 1.3/4 1.13/16 1.7/8 2
Overall length
mm 160 185 185 190 190 195 195 205 210 225 225 225 240 240 250
Head thickness
mm 15 15,5 15,5 16,5 16,5 16,5 16,5 19,5 20 20,5 20,5 20,5 22,5 22,5 23,5
Weight
Kg 0,250 0,350 0,350 0,400 0,400 0,450 0,450 0,750 0,725 0,850 0,850 0,850 1,050 1,050 1,250
843GP
Each 32,50 32,10 36,40 36,40 39,60 39,60 42,10 42,90 42,90 63,10 63,10 74,10 74,10 74,10 87,90
Opening
inches
2.1/16 2.1/8 2.3/16 2.1/4 2.3/8 2.7/16 2.9/16 2.5/8 2.3/4 3 3.1/8 3.3/8 3.1/2 3.3/4 3.7/8
Overall length
mm 250 250 270 270 270 270 290 290 320 325 345 360 390 400 420
Head thickness
mm 23,5 23,5 25
25
26
26
29
29 32,5 34
35
36
40 41,5 45
Weight
Kg 1,250 1,320 1,550 1,550 1,650 1,650 2,300 2,300 2,600 3,350 3,800 3,550 5,430 5,700 6,800
843GP
Each 88,40 120,00 116,00 116,00 116,00 118,00 147,00 147,00 160,00 169,00 235,00 396,00 464,00 427,00 631,00
Opening
inches
4 4.1/8 4.1/2
Overall length
mm 420 420 450
Head thickness
mm 45
45
48
Weight
Kg 6,800 6,300 7,900
843GP
Each 1.020,00 891,00 916,00
Sizes 1 and 1.3/8 inch with UNIT DRIVE shaped opening.
