223 / 1378
223
BIHEXAGON RING SLOPPING SPANNERS
223
3
Prices in EURO - VAT not included
BIHEXAGON RING SLOPPING SPANNERS
849G
849GP
Orig. Gedore - Art. 133
In forged CHROME VANADIUM steel up to a length of 500mm, in forged SPECIAL STEEL from a
length of 525mm. Single ended. Grey sandblasted finish.
Heavy duty. For use with hammers or sledge hammers. Dimensions according to DIN 133.
Opening
mm
22
24
27
30
32
34
36
41
46
50
55
60
65
Overall length
mm 180
180
180
190
195
195
210
225
255
280
310
320
350
Head thickness
mm 16
16
16,5
17
17,5 17,5 18,5 19,5
20
21,5 24,5 24,5
28
Weight
Kg 0,280 0,280 0,400 0,450 0,500 0,640 0,700 0,950 1,300 1,700 2,250 2,700 3,300
849G
Each 31,10 34,60 29,60 31,60 32,50 43,70 37,70 50,30 64,20 70,50 94,10 94,70 125,00
Opening
mm
70
75
80
85
90
95
100
105
110
115
120
125
130
Overall length
mm 370
400
405
405
455
455
500
500
500
525
525
545
575
Head thickness
mm 30
31,5 34,5 34,5
39
39
47
47
47
55
55
50
55
Weight
Kg 3,900 5,250 6,000 6,100 8,000 8,100 13,200 12,900 12,900 17,200 17,250 17,300 20,000
849G
Each 151,00 198,00 201,00 214,00 322,00 333,00 585,00 635,00 644,00 861,00 891,00 982,00 1.270,00
Opening
mm
135
140
145
150
155
160
165
170
175
Overall length
mm 575
640
640
640
640
715
715
715
715
Head thickness
mm 55
60
60
60
60
70
70
70
70
Weight
Kg 20,000 20,000 28,000 28,000 28,000 28,000 35,000 35,000 35,000
849G
Each 1.330,00 1.420,00 1.990,00 2.060,00 2.590,00 2.400,00 2.600,00 3.550,00 4.180,00
While stocks last measures mm 22-24 become SCU.
Sizes 155 - 175 running out of stock.
Product description as Art. 849G
MODEL WITH OPENINGS IN US INCH SIZES
Opening
inches
1
1.1/16 1.1/8 1.3/16 1.1/4 1.5/16 1.3/8 1.7/16 1.1/2 1.5/8 1.11/16 1.3/4 1.13/16
Overall length
mm 180
180
180
190
190
195
195
210
210
225
225
225
255
Head thickness
mm 16,5 16,5 16,5
17
17
17,5 17,5 18,5 18,5 19,5 19,5 19,5
20
Weight
Kg 0,340 0,330 0,310 0,450 0,450 0,500 0,500 0,700 0,700 0,950 0,950 0,950 1,300
849GP
Each 48,10 46,70 43,40 55,50 48,10 45,70 50,30 52,10 52,10 74,80 71,50 80,30 80,10
Opening
inches
1.7/8
2
2.1/16 2.1/8 2.3/16 2.1/4 2.3/8 2.7/16 2.9/16 2.5/8 2.3/4
3
3.1/8
Overall length
mm 255
280
280
280
310
310
320
320
350
350
370
400
405
Head thickness
mm 20
21,5 21,5 21,5 24,5 24,5 24,5 24,5
28
28
30
31,5 34,5
Weight
Kg 1,300 1,700 1,700 1,700 2,250 2,250 2,700 2,700 3,300 3,300 3,900 5,250 6,000
849GP
Each 84,30 106,00 115,00 126,00 144,00 127,00 145,00 133,00 195,00 175,00 282,00 265,00 239,00
Opening
inches
3.3/8 3.1/2 3.3/4 3.7/8
4
4.1/8 4.1/2
Overall length
mm 405
455
455
500
500
500
525
Head thickness
mm 34,5
39
39
47
47
47
55
Weight
Kg 6,100 8,000 8,100 12,900 12,900 12,900 17,200
849GP
Each 277,00 370,00 373,00 670,00 670,00 1.030,00 1.390,00
BIHEXAGONRINGSLOPPINGSPANNERS
SINGLE ENDED OPEN JAW SPANNERS
850G
Orig. Gedore - Art. 894
In CHROME VANADIUM steel.
Phosphate finish up to 38mm, sandblasted finish from 41mm.
Dimensions according to DIN 894. With hole.
Opening
mm
6
7
8
9
10
11
12
13
14
15
16
17
19
22
24
Overall length
mm 73
78
94 100 106 112 124 132 140 145 155 159 170 193 217
Head thickness
mm 3,2 3,2 3,5
4
4,5
5
5
5,5 5,5 5,5 5,5
6
7
8
9
850G
Each 3,64 3,64 3,64 3,70 3,70 4,10 4,36 4,36 4,50 5,66 5,68 4,56 5,60 6,58 8,82
Opening
mm
25
27
30
32
34
36
38
41
46
50
55
60
65
70
75
Overall length
mm 217 239 263 275 290 305 305 344 380 413 459 494 528 572 610
Head thickness
mm 9
9,8 10,8 11,8 12,3 12,8 12,8 13,8 14,8 15,8 16,8 17,7 18,7 19,7 20,7
850G
Each 9,24 10,40 12,50 13,90 24,60 19,40 21,60 23,80 31,30 39,30 44,30 57,50 68,50 87,60 102,00
Opening
mm
80
85
90
95 100 105 110 115 120 125 130
Overall length
mm 645 688 740 740 847 1000 1000 1000 1000 1000 1000
Head thickness
mm 21,7 22,7 24,6 24,6 25
28
28
28
28
28
27
850G
Each 129,00 176,00 213,00 295,00 308,00 424,00 444,00 606,00 617,00 829,00 861,00
SINGLEENDEDOPEN JAWSPANNERS
850R
Prod. SCU
In steel. Nickel finish. Dimensions according to DIN 894.
Opening
mm
6
7
8
9
10
11
12
13
850R
Each 0,70 0,74 0,74 0,74 0,76 0,80 0,80 0,90
Opening
mm
14
15
16
17
18
19
22
24
850R
Each 1,00 1,18 1,18 1,28 1,34 1,38 1,94 2,26
Opening
mm
27
30
32
36
38
40
41
46
850R
Each 2,66 3,70 4,50 5,70 6,92 7,60 7,60 10,50
Opening
mm
50
55
60
65
70
75
80
85
850R
Each 13,80 23,50 34,40 43,90 66,80 97,10 119,00 132,00
SINGLEENDEDOPEN JAWSPANNERS
