ELECTRONICS WIRE STRIPPERS
23
2
Prices in EURO - VAT not included
WIRE STRIPPERS FOR FIBRE OPTICS
180G
Prod. SCU
In special steel. Hardened noses. Dual component handles. With adjustment system for stripping
wires without causing damage. Double wire stripper to remove primary and secondary coating
from wires max Ø up to 125 µm.
Overall length
mm 135
180G
Each 90,80
vuoto
ELECTRONICSWIRESTRIPPERS
WIRE STRIPPERS FOR TEFLON INSULATION
181G
Prod. SCU
In special steel. Hardened noses. Dual component handles. With double-step adjustment/
clamping system for stripping PTFE-coated copper wires from 0,005 to 0,14 sqmm (AWG 40-26).
First step for wires 0,02/0,01 sqmm. and 0,008/0,005 (AWG 34/36 and 38/40).
Second step for wires 0,14/0,08 sqmm. And 0,06/0,03 sqmm (AWG 26/28 and 30/32).
Overall length
mm 135
181G
Each 110,00
vuoto
WIRE STRIPPER
186
Prod. SCU
Interchangeable jaws in hardened steel. Plastic gripping pads.
Wires Ø
mm
0,5
0,6
0,8
1,0
Overall length
mm 130
130
130
130
186
Each 7,04
7,04
7,04
7,04
vuoto
WIRESTRIPPER
186G
Versatile and compact, body made of synthetic material. Suitable for stripping any kind of
standard cables as well as RG 58/59/62 coaxial cables, UTP and STP cables. Adjustable blade
cutting depth.
Overall length
mm 100
For cables with ext. Ø mm 0,75 to 10
186G
Each 19,10
vuoto
WIRESTRIPPER
187G
Suitable for stripping coaxial cables and highly flexible cables. Adjustable blade cutting depth by
pressing the operating parts. Opening spring and locking button. Body made of synthetic material
reinforced with fiberglass. Of small dimensions for places difficult to access.
Overall length
mm 110
Capacity for sections
mm
2
3x0.75-10-16
For co-axial cables with ext. Ø mm 4,8 to 7,5
187G
Each 18,20
vuoto
WIRESTRIPPER
188G
Suitable for stripping very long coaxial cables and highly flexible cables. Adjustable blade cutting
depth by jaw pressure. Body made of synthetic material reinforced with fiberglass. Side cable
cutter.
Overall length
mm 120
Capacity for sections
mm
2
3x0.75-10-16
For co-axial cables with ext. Ø mm 4,8 to 7,5
188G
Each 22,50
vuoto
WIRESTRIPPER
189G
Universal type suitable for stripping wires, cables and coaxial cables. Used for removing the
insulating covering, both longitudinally and transversally. Adjustable blade by jaw pressure. Plastic
handle.
Overall length
mm 135
Capacity for sections
mm
2
0,5 to 16
For co-axial cables with ext. Ø mm 4 to 8
For cables with ext. Ø
mm 4 to 13
189G
Each 20,50
vuoto
WIRESTRIPPER
190G
Spring type. Suitable for automatically removing the insulating covering from conductors.
Body made of synthetic material reinforced with fiberglass. Steel blades.
With indication of the stripping length from 8mm to 20mm. Wire cutter included.
Overall length
mm 150
Capacity for sections
mm
2
0,5 to 6
190G
Each 21,80
vuoto
Spare blades for Art.190 G.
O190G
Per pair
5,04
vuoto
WIRESTRIPPER
