CABLE STRIPPER FOR INDUSTRIAL USE
28
2
Prices in EURO - VAT not included
202GA
202GB
For removing thick insulating sheaths from large conductors through circular, longitudinal and
diagonal cutting. Body in high-resistance steel and die-cast ALUMINIUM alloy. SUPER-RAPID
steel blade. With micrometric screw for blade depth adjustment
. Knife step-rotation by 45° - 90° - 180°. Extractable handle for adjustment and clamping in the
desired diameters. With rollers for easy sliding on the sheath, rapid closing for cable clamping.
Capacity for Ø
mm 16 to 36
Blade max depth
mm 5
Weight
grams 580.
202GA
Each 209,00
Product running out of stock.
vuoto
Product description as Art. 202GA
The 202 GB type is equipped with 2 inserts:
length mm 95 for cables ext. Ø from 30 to 52 mm
length mm 127 for cables ext. Ø from 20 to 44 mm.
Capacity for Ø
mm 20 to 52
Blade max depth
mm 5
Weight
grams 640
202GB
Each 580,00
vuoto
Spare blades for Art.202 GA-B.
O202G
Each 16,80
CABLESTRIPPER FOR INDUSTRIALUSE
202GC
For removing thick insulating sheaths from conductors through circular and longitudinal cutting.
Body in fiberglass reinforced polyamide.
Blade and knurled sliding wheel made of steel. Blade depth adjustment through
special screw. Reversible blade to be used in both directions and sides.
Capacity by Ø
mm 25
Blade max depth
mm 5
Overall length as closed mm 150
202GC
Each 389,00
vuoto
Spare blades for Art. 202 GC.
O202GC
Each 112,00
vuoto
CABLESTRIPPER FOR INDUSTRIALUSE
202GCE
Orig. Gedore - Art. 137 ISOCUT
For stripping ground or high voltage cables with 1 or more insulating layers up to a diameter of 42
mm. Allows the possibility to perform circular and longitudinal cuts by rotating the blade, and by
pressing the button on the head of the pliers. Adjustable screw depth cuttings. Immediate
clamping and release, covered by a lever. Drop forged jaws and a hardened body made from
sturdy sheet steel.
Capacity for Ø up to
mm 42
Cutting max depth
mm 14
Weight
Kg 0,840
202GCE
Each 217,00
Product running out of stock.
vuoto
CRIMPING PLIERS FOR COAXIAL CONNECTORS
202GCP
Orig. Gedore - Art. 8140
Professional modular ratchet crimping tool to crimp most of mechanical, electric and electronic
connectors.
The pliers can be equipped with different modular bits.
Use pros: crimping reliability and precision thanks to parallel stroke mechanism. User-friendly
due to perfect visibility during crimping process and rapid release function for bit replacement with
no tool required. Tool lightness assures max. comfort. Easy- to-use thanks to the interchangeable
modular bits clearly marked according to their use. Versatility and low price for a pliers to be used
with different kinds of connectors (power, coaxial, phone and optical fibres connectors).
PLIERS WITHOUT BITS
Overall length
mm 234
202GCP
Each 108,00
CRIMPINGPLIERSFORCOAXIALCONNECTORS
