DIAMOND-COATED CORE DRILLS
400
4
Prices in EURO - VAT not included
DIAMOND-COATED CORE DRILLS
1350GA
Prod. SCU
Segment-type with sintered diamond powder (cores). For DRY drilling of walls, floors, ceiling, etc.
With side discharge for easier ejection of waste parts and better cooling. To be used with
perforators Art. 1352 G. 1/2" BSP external threaded connection.
Ø
mm
32
44
53
63
71
83
Overall length
mm 300
300
300
300
300
300
1350GA
Each 182,00 203,00 223,00 243,00 263,00 304,00
vuoto
DIAMOND-COATEDCOREDRILLS
1350GB
Segment-type with sintered diamond powder (cores). For WET drilling of walls, floors, ceilings,
etc. To be used with perforators Art. 1352 G. 1/2" BSP external threaded connection.
Ø
mm
12
18
26
32
44
53
63
Overall length
mm 120
220
320
320
320
320
320
1350GB
Each 91,10 108,00 132,00 152,00 182,00 203,00 223,00
Ø
mm
71
83
Overall length
mm 320
320
1350GB
Each 263,00 324,00
vuoto
DIAMOND-COATEDCOREDRILLS
1351G
Extensions for drill bits Art. 1350 GA - B.
To be used with perforators Art. 1352 G.
Overall length
mm
200
260
Ø
mm 30
30
1351G
Each 151,00 238,00
vuoto
DIAMOND-COATEDCOREDRILLS
ELECTRIC CORING BURS FOR DIAMOND-COATED CROWN DRILLS
1352G
Prod. SCU
Handy electric perforator for diamond crown wheels Art. 1350 GA-B, extensions Art. 1351 G and
all crown wheels with 1/2" BSP external threaded connection and 1.1/4" UNC internal threaded
connection. Equipped with anti-vibration system and progressive start-up device for drilling
without damaging perforated surfaces. With double handle, one of which adjustable and rest on
breast for stronger horizontal thrust. For drilling concrete up to Ø 83mm.
With rubber-holder tap and rubber pipe length approx. 2.5mm to let chuck water pass through in
case of drilling in damp or humid areas.
1/2" BSP internal threaded connection. 1.1/4" UNC external threaded connection.
Double speed from 0 to 950 / 0 to 2100 rpm.
Monophase engine 230 V, absorbed power 1500 W. Weight 7.5 kg.
1352G
Each 1.300,00
vuoto
ELECTRICCORINGBURSFORDIAMOND-COATEDCROWNDRILLS
VALVE GRINDER MACHINES
1378G
Orig. Gedore - Art. 653
Type for grinding valve seats, cocks and gears.
With left/right rotation movement, for hand use.
Wooden handgrip. Supplied with 1 rubber suction cup with a diameter of 25mm.
Length 275mm.
1378G
Each 9,00
vuoto
Spare suckers for Art. 1378 G.
Ø
mm
20
25
30
37
O1378G
Each 3,04
3,16
3,92
4,72
vuoto
VALVEGRINDERMACHINES
VALVE GRINDER MACHINES
1380G
Orig. Gedore - Art. 654
Type for grinding valve seats, cocks and gears. With left/right automatic movement, for electric
drill use.
Supplied with 4 rubber suction cups with a diameter of 20 - 25 - 30 - 37mm. Coonection dia.
8mm, length 135mm.
1380G
Each 260,00
For spare suckers see Art. 01378 G x 20 - 25 - 30 - 37.
vuoto
VALVEGRINDERMACHINES
