EXTRACTORS FOR BROKEN TAPS

402

5

Prices in EURO - VAT not included

EXTRACTORS FOR BROKEN TAPS

1404GA

Prod. SCU

Suitable for extracting any kind of broken screw tap inside the piece during screw-cutting.

The choice of the extractor to use depends on the kind of tap to remove according to diameter

and number of discharge slots.

The extraction is carried out with movements of the tap wrench mounted on the square

connection of the tool.

LOOSE EXTRACTORS

Suitable for double-slot taps.

For males Ø

mm

3

4

5

6

8

10

12

For males Ø

inches 1/8

5/32

3/16

1/4

5/16

3/8

1/2

Size

0

1

2

3

4

5

6

1404GA

Each 12,20 12,20 12,20 12,20 12,20 14,10 14,10

For males Ø

mm

14

16

20

22

24

For males Ø

inches 9/16

5/8

3/4

7/8

1

Size

7

8

9

10

11

1404GA

Each 14,10 18,90 18,90 18,90 29,80

vuoto

EXTRACTORSFORBROKEN TAPS

1404GB

Product description as Art. 1404GA

LOOSE EXTRACTORS

Suitable for triple-slot taps.

For males Ø

mm

3

4

5

6

8

10

12

For males Ø

inches 1/8

5/32

3/16

1/4

5/16

3/8

1/2

Size

0

1

2

3

4

5

6

1404GB

Each 12,20 12,20 12,20 12,20 12,20 14,10 14,10

For males Ø

mm

14

16

20

22

24

For males Ø

inches 9/16

5/8

3/4

7/8

1

Size

7

8

9

10

11

1404GB

Each 14,10 18,90 18,90 18,90 29,80

vuoto

EXTRACTORSFORBROKEN TAPS

1404GC

Product description as Art. 1404GA

LOOSE EXTRACTORS

Suitable for quadruple-slot taps.

For males Ø

mm

6

8

10 12 14 16 20 22 24

For males Ø

inches 1/4 5/16 3/8 1/2 9/16 5/8 3/4 7/8

1

Size

3

4

5

6

7

8

9

10 11

1404GC

Each 12,20 12,20 14,10 14,10 14,10 18,90 18,90 18,90 29,80

vuoto

EXTRACTORSFORBROKEN TAPS

EXTRACTORS FOR BROKEN TAPS IN SET

1405G 1

1405G 2

Prod. SCU

Suitable for extracting any kind of broken screw tap inside the piece during screw-cutting. The

choice of the extractor to use depends on the kind of screw tap to remove according to diameter

and number of splines. The extraction is carried out with movements of the tap wrench mounted

on the square connection of the tool.

Suitable for taps with 3 - 4 splines.

The set is composed of:

1404 GB 4-5-6-8

1404 GC 10-12.

1405G 1

Per set 80,10

vuoto

Product description as Art. 1405G 1

The set is composed of:

1404 GB 5-6-8

1404 GC 10-12-14-16-20-22.

1405G 2

Per set 140,00

vuoto

EXTRACTORSFORBROKEN TAPS INSET

EXTRACTORS FOR BROKEN SCREWS

1405GA

Prod. SCU

Reversible type enbloc, with one end pointed and the other with extractor. Suitable for extracting

broken or headless screws even made of stainless steel.

. Use with left/right rotation electric drills.

For screws

M.

3

4

5

Overall length

mm 29

32

35

1405GA

Each 21,10 21,80 22,40

vuoto

EXTRACTORSFORBROKENSCREWS

1405GB

Two-piece combination of bit/extractor ring. Suitable for extracting - in one action - broken or

headless screws, even made of stainless steel.

Use with left/right rotation electric drills.

Max. drilling depth: 12mm. Hexagonal shank.

For screws

M.

6

8

10

12

Overall length

mm 28

32

36

40

1405GB

Each 26,70 29,30 31,10 37,30

vuoto

EXTRACTORSFORBROKENSCREWS
