417 / 1378
417
SETS OF ASSORTED DOUBLE-GRIP EXTRACTORS
417
5
Prices in EURO - VAT not included
SETS OF ASSORTED DOUBLE-GRIP EXTRACTORS
1425GB
Orig. Buco - Art. 16/ST
Composed of 5 extractors Art. 1425 G with elegant and handy wooden display stand also for
workshops.
Extractors opening: 80 - 130 - 160 - 200 – 250mm.
1425GB
Each 919,00
vuoto
SETSOFASSORTEDDOUBLE-GRIPEXTRACTORS
UNIVERSAL DOUBLE-GRIP HYDRAULIC EXTRACTORS
1425GF
Orig. Buco - Art. HY 16
Hydraulic pivot type.
Made of forged hardened steel. Wide range of use, inside/outside use. Normal and long arms,
interchangeable, sliding on ground guides. This kind of arms gives parallel traction stresses. Zinc-
chrome plated finish.
Acting by means of a key on the upper screw of the pivot, the operator will obtain hydraulic
pressures equal to some tons.
Max opening
mm
250
350
520
640
Useful length
mm 200
200
200
225
Maximum pressure:
t.
13
13
15
15
Weight
Kg
8,5
9,4
14,3
25
1425GF
Each 637,00 666,00 864,00 1.660,00
For spare and additional arms see Art. 1425 GM-P.
vuoto
UNIVERSALDOUBLE-GRIPHYDRAULICEXTRACTORS
LOOSE ARMS FOR EXTRACTORS
1425GM
Orig. Buco
Complete with connections and bolts. For Art. 1425 G - 1425 GF - 1433 GE - 1433 GL - 1433 GR.
Standard type.
Size
1
2
3
4
Useful length
mm 100
150
200
225
For extractors opening
mm 80-130 160-200 250-520 640
1425GM
Each 28,40 51,10 87,30 158,00
vuoto
LOOSEARMSFOREXTRACTORS
1425GP
Product description as Art. 1425GM
Long type.
Size
1
2
3
4
5
6
7
Useful length
mm 200
300
300
300
400
400
500
For extractors opening
mm 80-130 160-200 250-520 640 250-520 640 250-520
1425GP
Each 40,40 75,50 120,00 210,00 148,00 244,00 154,00
Size
8
Useful length
mm 500
For extractors opening
mm 640
1425GP
Each 294,00
vuoto
LOOSEARMSFOREXTRACTORS
RAPID ADJUSTMENT EXTRACTORS WITH TWO THIN ARMS
1425GPE
GRADUATED
Orig. Gedore
Made from hardened, forged steel.
Arms with a quick release lever which allows faster and more accurate adjustments. Wide range
of use for both indoor and outdoor conditions. Interchangeable arms which can slide onto ground
based fittings, and with thin legs which can fit into very narrow positions. The type of arms allows
for parallel traction stresses. Zinc-chrome plated.
Max opening
mm
100
140
160
200
Useful length
mm
100
100
150
150
Maximum pressure:
t
2
2,5
5
5
Weight
Kg
1
1,1
2,9
3,2
Height a
mm
3,7
3,7
5
5
Height b
mm
7,5
7,5
7
7
Height c
mm
13
13
17
17
Height d
mm
27
27
40
40
Screw x length Ø
mm M 14x1,5x140 M 14x1,5x140
G 1/2x210
G 1/2x210
Supplier code
1.06/S1-E
1.06/S1A-E
1.06/S2-E
1.06/S2A-E
1425GPE
Each
141,00
146,00
230,00
253,00
For spare arms see Art. 1425 GPF. For spare screws see Art. 1455 GA.
vuoto
RAPIDADJUSTMENTEXTRACTORSWITHTWOTHINARMS
