UNIVERSAL TRIPLE GRIP PULLERS
423
5
Prices in EURO - VAT not included
1433G
Orig. Buco - Art. 13
Made of steel. With arms forged in one piece.
Strong H-beam arm rest with trapezoidal stiffener. Heavy-duty type. Reversable arms for inside/
outside use. Easy sliding opening with automatic stop in traction.
Size
1A
2
2A
Max opening
mm 120
160
200
Useful length
mm 100
150
150
Weight
Kg
1,4
3,7
4,3
1433G
Each 140,00 243,00 268,00
For spare and additional arms see Art. 1423 GA and 1423 GB. Sizes 2 and 2A may be supplied
with hydraulic pivot on request.
vuoto
UNIVERSALTRIPLEGRIPPULLERS
UNIVERSAL TRIPLE GRIP EXTRACTORS, THIN ARMS.
1433GA
Orig. Gedore
Hot-stamped steel.
Wide range of use, inside/outside use. Normal and long arms, interchangeable, sliding on ground
guides with thin ends and feet to be inserted in very narrow spaces. This kind of arms ensures
parallel traction stresses. Zinc-chrome plated finish.
Max opening
mm
90
130
160
200
Useful length
mm
100
100
150
150
Maximum pressure:
t.
2,5
2,5
5,0
5,0
Weight
Kg
1,3
1,4
3,6
4
Height a
mm
3,6
3,6
5
5
Height b
mm
7,5
7,5
7
7
Height c
mm
13
13
17
17
Height d
mm
27
27
40
40
Screw x length Ø
mm M 14x1,5x140 M 14x1,5x140
G 1/2x210
G 1/2x210
Supplier code
1.07/S1
1.07/S1A
1.07/S2
1.07/S2A
1433GA
Each
188,00
208,00
340,00
363,00
Spare arms can be supplied on request. For spare screw see Art. 1455 GA.
vuoto
UNIVERSALTRIPLEGRIPEXTRACTORS,THINARMS.
ASSORTMENT OF EXTRACTORS WITH THREE THIN ARMS
1433GAM
Orig. Gedore - Art. 1.07/AS
Hot-stamped steel.
Wide range of use, inside/outside use. Normal and long arms supplied, interchangeable, sliding
on ground guides with thin ends and feet to be inserted in very narrow spaces. This kind of arms
ensures parallel traction stresses. Zinc-chrome plated finish.
Composition:
1 cross-beam rest for 3 arms max. aperture 130mm
3 arms length 100mm
3 arms length 200mm
3 arms length 250mm
1433GAM
Per set 586,00
Spare arms can be supplied on request.
vuoto
ASSORTMENTOFEXTRACTORSWITHTHREETHINARMS
ASSORTMENT OF EXTRACTORS WITH THIN ARMS
1433GAR
Orig. Gedore - Art. 1.07/K
Composed of extractors with 2 or 3 thin arms of varying length, which can slide onto ground
fittings, and which can be inserted into very narrow positions. The type of arms allows for parallel
traction stresses. T shaped cross pieces, reinforced. Zinc-chrome plated.
Comprising:
3 arms, length 100/200/250mm
1 cross-beam with 2 arms, max. aperture 130mm
1 cross-beam with 3 arms, max. aperture 130mm
2 threaded screws M 14 x 1.5 x 140 (Art. 1455 GA 1).
Complete set. In a case.
1433GAR
Each 680,00
Spare parts can be supplied on request.
