425 / 1378
425
UNIVERSAL TRIPLE GRIP PULLERS
425
5
Prices in EURO - VAT not included
1433GH
Orig. Gedore - Art. 1.07/4
Hardened steel body, CHROME-VANADIUM steel arms.
Heavy type for heavy-duty works, with clamp for both inside/outside use.
Normal and long arms, interchangeable. This kind of arms ensures parallel traction stresses.
Max opening
mm 450
Useful length
mm 200
Maximum pressure:
t
10
Weight
Kg
19
Screw x length Ø
mm G 1x360
1433GH
Each 1.160,00
When the threaded screw and reduction is removed the extractor can be used with hydraulic
system Art. 1446 GA.
For spare arms and additional accessories see Art. 1424 GPA 3 - 1424 GRA 3-4-5. For spare
screw (manual or hydraulic) see Art. 1455 G
vuoto
UNIVERSALTRIPLEGRIPPULLERS
1433GL
Orig. Buco - Art. 17
Made of forged and hardened steel. Heavy type, of large size.
Wide range of use, inside/outside use.
Normal and long arms, interchangeable, sliding on ground guides.
This kind of arms gives parallel traction stresses.
Max opening
mm
250
380
520
640
Useful length
mm 200
200
200
200
Weight
Kg
8,6
19
22
26
1433GL
Each 541,00 1.050,00 1.230,00 1.290,00
For spare and additional arms see Art. 1425 GM 3-4 and 1425 GP 3-4-5-6-7-8.
vuoto
UNIVERSALTRIPLEGRIPPULLERS
STANDARD TRIPLE GRIP PULLERS
1433GR
Orig. Buco - Art. HY17
Hydraulic pivot type.
Made of forged steel. Heavy type, of large size.
Wide range of use, inside/outside use.
Normal and long arms, interchangeable.
This kind of arms gives parallel traction stresses.
Acting by means of a key on the upper screw of the pivot, the operator will obtain hydraulic
pressures equal to some tons.
Max opening
mm
380
520
640
Useful length
mm 200
200
200
Maximum pressure:
t.
15
15
15
Weight
Kg
23
26
29
1433GR
Each 1.430,00 1.750,00 1.810,00
For spare and additional arms see Art. 1425 GM 3-4 and 1425 GP 3-4-5-6-7-8.
vuoto
STANDARDTRIPLEGRIPPULLERS
RAPID ADJUSTMENT EXTRACTORS WITH THREE THIN ARMS
1433GT
Orig. Gedore
Made from hardened, forged steel.
Arms with a quick release lever which allows faster and more accurate adjustments. Wide range
of use for both indoor and outdoor conditions. Interchangeable arms which can slide onto ground
based fittings, and with thin legs which can fit into very narrow positions. The type of arms allows
for parallel traction stresses. Zinc-chrome plated.
Max opening
mm
90
130
160
200
Useful length
mm
100
100
150
150
Maximum pressure:
t.
2,5
2,5
5,0
5,0
Weight
Kg
1,3
1,4
3,6
3,9
Height a
mm
3,7
3,7
5
5
Height b
mm
7,5
7,5
7
7
Height c
mm
13
13
17
17
Height d
mm
27
27
40
40
Screw x length Ø
mm M 14x1,5x140 M 14x1,5x140
G 1/2x210
G 1/2x210
Supplier code
1.07/S1-E
1.07/S1A-E
1.07/S2-E
1.07/S2A-E
1433GT
Each
200,00
221,00
357,00
369,00
For spare arms see Art. 1425 GPF.
