INSTRUMENTS FOR SHEET OF METAL
665
9
Prices in EURO - VAT not included
INSTRUMENTS FOR SHEET OF METAL
2810T
Prod. SCU
Tools for the cold pulling of hail dents, stone dents, etc. without removing paint. Particularly
suitable to body-makers, repairers, etc.
Together with the pulling tool the following items are supplied:
6 pulling inserts in plastic of different type and shape
20 resin sticks of different tenacities Art. 3252 F 3-5 (10 pcs. for item)
1 x rubber-coated plate for small dents
2 x rubber-coated support feet for big dents and rounded surfaces
Complete set with inserts and accessories supplied in plastic case.
2810T
Each 462,00
Further resin sticks: see Art. 3252 F 1-3-6
Product running out of stock.
vuoto
INSTRUMENTSFORSHEETOFMETAL
ELASTIC PIN SETS
2810Z
Prod. SCU
Set of elastic pins according to ISO 8752 DIN 1481, burnished finish. In spring steel C 70-55 Si 7.
517-pcs. set of elastic pins Art. 2811.
The set contains:
50 pcs. each mm 3x22 - 3x40
40 pcs. each mm 4x16 - 4x22 - 4x30 - 4x40 - 4x50
24 pcs. each mm 5x30 - 5x50 - 5x60
30 pcs. each. mm 6x16
10 pcs. each mm 6x40 - 6x50 - 6x80
20 pcs. each mm 6x60
5 pcs. each mm 7x80
12 pcs. each mm 8x40 - 8x55 - 8x60 - 8x80
6 pcs. each mm 10x40 - 10x80
2810Z
Each 278,00
vuoto
ELASTICPINSETS
ELASTIC PINS
2811
Prod. SCU
Model according to ISO 8752 DIN 1481, burnished finish.
In spring special steel C70-55 Si7.
Beveled extremities in dimensions up to Ø 8mm.
Only one beveled extremities in dimensions from Ø 10mm.
Mentioned packing units are not sold separately. Product in set see Art.2810 Z.
Ø for length
mm
1x4 1x5 1x6 1x8 1x10 1x12 1x14 1x16 1x20 1.5x6 1.5x8 1.5x10 1.5x12 1.5x14 1.5x16
Indivisible pck.
Pz
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 31,90 33,30 33,30 33,30 34,70 34,70 36,10 38,90 43,10 20,80 22,20 22,20 22,90 25,10 30,50
Ø for length
mm
1.5x20 2x4 2x5 2x6 2x8 2x10 2x12 2x14 2x16 2x18 2x20 2x22 2x24 2x26 2x30
Indivisible pck.
Pz
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 34,70 27,80 27,80 23,60 23,60 23,60 25,10 25,10 25,10 25,10 26,40 27,80 31,90 33,30 36,10
Ø for length
mm
2.5x5 2.5x6 2.5x8 2.5x10 2.5x12 2.5x14 2.5x16 2.5x18 2.5x20 2.5x26 2.5x30 3x4 3x5 3x6 3x8
Indivisible pck.
Pz
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 25,10 25,10 25,10 25,70 25,70 25,70 26,40 26,40 27,80 36,10 41,60 25,10 25,10 25,10 26,40
Ø for length
mm
3x10 3x12 3x14 3x16 3x18 3x20 3x22 3x24 3x26 3x28 3x30 3x32 3x36 3x40 3.5x10
Indivisible pck.
Pz
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811
Per pack 26,40 27,80 29,20 31,90 31,90 31,90 33,30 33,30 34,70 34,70 36,10 38,90 43,10 44,40 41,60
Ø for length
mm
3.5x12 3.5x16 3.5x20 3.5x26 3.5x30 3.5x36 3.5x40 4x6 4x8 4x10 4x12 4x14 4x16 4x18 4x20
Indivisible pck.
Pz
1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 500 500 500
2811
Per pack 36,10 38,90 40,20 44,40 50,10 52,70 55,50 15,30 16,10 16,70 16,70 17,40 18,80 18,80 19,50
Ø for length
mm
4x22 4x24 4x26 4x28 4x30 4x32 4x36 4x40 4x45 4x50 4.5x16 4.5x20 4.5x24 4.5x30 4.5x32
Indivisible pck.
Pz
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811
Per pack 19,50 20,10 21,50 22,20 22,90 23,60 25,70 28,50 30,50 38,20 29,20 31,20 34,70 38,20 39,60
Ø for length
mm
4.5x40 5x6 5x10 5x12 5x14 5x16 5x18 5x20 5x22 5x24 5x26 5x30 5x32 5x36 5x40
Indivisible pck.
Pz
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811
Per pack 45,80 25,10 20,80 20,80 21,50 24,30 24,30 25,10 27,10 28,50 29,80 31,20 32,60 35,40 37,50
Ø for length
mm
5x45 5x50 5x55 5x60 5x65 5x70 5x80 6x10 6x12 6x14 6x16 6x18 6x20 6x22 6x24
Indivisible pck.
Pz
500 250 250 250 250 250 250 500 500 500 500 500 500 500 500
2811
Per pack 38,90 21,90 24,10 26,10 31,90 31,90 36,40 25,70 26,40 27,10 29,20 29,20 29,80 31,20 34,70
