ELASTIC PINS
666
9
Prices in EURO - VAT not included
Ø for length
mm
6x26 6x30 6x32 6x36 6x40 6x45 6x50 6x55 6x60 6x65 6x70 6x75 6x80 6x100 7x20
Indivisible pck.
Pz
500 500 500 500 250 250 250 250 250 250 250 250 250 250 500
2811
Per pack 38,20 41,60 44,40 49,30 25,10 27,80 31,20 33,10 34,70 45,10 45,10 55,50 62,40 101,00 57,60
Ø for length
mm
7x26 7x30 7x40 7x50 7x60 8x12 8x16 8x20 8x24 8x26 8x30 8x32 8x36 8x40 8x45
Indivisible pck.
Pz
500 250 250 500 250 500 500 500 500 250 250 250 250 250 250
2811
Per pack 72,80 41,60 48,60 118,00 76,30 42,30 44,40 47,90 54,80 31,20 33,70 34,70 41,60 41,60 45,10
Ø for length
mm
8x50 8x55 8x60 8x65 8x70 8x80 8x100 10x14 10x16 10x20 10x22 10x24 10x26 10x30 10x32
Indivisible pck.
Pz
250 250 250 250 250 250 100 500 500 500 500 500 500 500 500
2811
Per pack 48,60 52,10 55,50 59,10 65,90 90,20 50,10 69,40 72,80 90,20 97,10 104,00 104,00 111,00 125,00
Ø for length
mm
10x36 10x40 10x45 10x50 10x55 10x60 10x65 10x70 10x80 10x90 10x100 12x16 12x20 12x24 12x30
Indivisible pck.
Pz
250 250 250 250 250 200 200 100 100 100 100 500 500 250 250
2811
Per pack 62,40 65,90 72,80 79,80 86,70 77,70 83,20 45,80 51,30 61,00 76,30 728,00 347,00 191,00 208,00
Ø for length
mm
12x36 12x40 12x45 12x50 12x60 12x70 12x80 12x90 12x100 12x120
Indivisible pck.
Pz
200 200 100 100 100 100 50
50
50
50
2811
Per pack 167,00 167,00 83,20 90,20 97,10 97,10 52,10 83,20 125,00 160,00
FITTING TOLERANCE RANGE:
nominal Ø of pin from 1 to 3mm = tolerance (H12) mm +0.10
nominal Ø of pin from 3.5 to 6mm = tolerance (H12) mm +0.12
nominal Ø of pin from 7 to 10mm = tolerance (H12) mm +0.15
nominal Ø of pin 12mm = tolerance (H12) m
vuoto
ELASTICPINS
SPIRAL PINS
2811E
Prod. SCU
Model according to ISO 8750 DIN 7343, burnished finish.
In spring special steel C70-55 Si7.
All dimensions have beveled extremities. The spiral cross-section gives high elasticity allowing
these pins an excellent bearing capacity to support dynamic loads.
Mentioned packing units are not sold separately.
Ø for length
mm
1x6 1x8 1x10 1x12 1.5x6 1.5x8 1.5x10 1.5x12 1.5x14 2x5 2x6 2x8 2x10 2x12 2x14
Indivisible pck.
Pz 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811E
Per
pack 52,70 54,10 54,10 55,50 40,20 40,20 40,90 41,60 45,80 37,50 38,90 40,20 41,60 43,10 44,40
Ø for length
mm
2x16 2x18 2x20 2.5x5 2.5x6 2.5x8 2.5x10 2.5x12 2.5x14 2.5x16 2.5x18 2.5x20 3x6 3x8 3x10
Indivisible pck.
Pz 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811E
Per
pack 44,40 47,20 48,60 41,60 41,60 41,60 41,60 43,10 44,40 47,20 48,60 52,70 43,10 43,10 47,20
Ø for length
mm
3x12 3x14 3x16 3x18 3x20 3x22 3x24 3x26 3x28 3x30 3.5x10 3.5x16 3,5x18 3.5x20 3.5x30
Indivisible pck.
Pz 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
2811E
Per
pack 48,60 50,10 50,10 51,30 52,70 54,10 55,50 56,90 58,30 61,00 56,90 65,20 65,20 69,40 83,20
Ø for length
mm
4x8 4x10 4x12 4x14 4x16 4x18 4x20 4x22 4x24 4x26 4x28 4x30 4x32 4x36 4x40
Indivisible pck.
Pz
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811E
Per
pack 27,10 27,80 28,50 29,80 30,50 32,60 32,60 33,30 34,10 35,40 36,80 38,20 40,90 45,10 49,30
Ø for length
mm
4x45 4x50 5x10 5x12 5x14 5x16 5x20 5x22 5x24 5x26 5x28 5x30 5x32 5x36 5x40
Indivisible pck.
Pz
500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
2811E
Per
pack 54,10 65,20 34,70 36,10 37,50 39,60 43,10 44,40 45,80 47,90 50,10 53,40 56,90 61,00 65,90
Ø for length
mm
5x45 5x50 5x60 6x12 6x14 6x16 6x18 6x20 6x22 6x24 6x26 6x30 6x32 6x36 6x40
Indivisible pck.
Pz
500 250 250 500 500 500 500 500 500 500 500 500 500 500 250
2811E
Per
pack 69,40 38,20 46,80 43,10 47,20 47,90 52,10 52,70 54,10 56,90 61,00 69,40 72,80 79,80 41,60
Ø for length
mm
6x45 6x50 6x55 6x60 6x65 6x70 8x20 8x26 8x28 8x30 8x32 8x36 8x40 8x45 8x50
Indivisible pck.
Pz
250 250 250 250 250 250 500 250 250 250 250 250 250 500 250
2811E
Per
pack 45,10 48,60 62,40 65,90 72,80 79,80 90,20 59,10 59,10 69,40 72,80 72,80 72,80 167,00 90,20
Ø for length
mm
8x55 8x60 8x70 8x80 8x100 10x22 10x24 10x26 10x28 10x30 10x32 10x35 10x40 10x45 10x50
Indivisible pck.
Pz
250 250 250 250 100 500 500 500 500 500 500 250 250 250 250
2811E
Per
pack 108,00 115,00 146,00 191,00 111,00 160,00 174,00 181,00 195,00 202,00 222,00 115,00 115,00 122,00 156,00
Ø for length
mm
10x60 10x70 10x80 10x90 10x100 12x24 12x30 12x40 12x50 12x60 12x70 12x80 12x90 12x100
Indivisible pck.
Pz
200 100 100 100 100 250 250 200 100 100 100 100 50
50
2811E
Per
pack 161,00 97,10 111,00 264,00 305,00 281,00 292,00 256,00 139,00 146,00 167,00 195,00 160,00 222,00
FITTING TOLERANCE RANGE:
nominal Ø of pin from 1 to 3mm = tolerance (H12) mm +0.10
nominal Ø of pin from 3.5 to 6mm = tolerance (H12) mm +0.12
nominal Ø of pin from 7 to 10mm = tolerance (H12) mm +0.15
nominal Ø of pin 12mm = tolerance (H12) m
vuoto
SPIRALPINS
