767 / 1378
767
INVERTER WELDING MACHINES
767
10
Prices in EURO - VAT not included
INVERTER WELDING MACHINES
3271A
Prod. SCU
Professional portable electric welding machines, monophasic alternate current. Conform to
European specifications EN 60974-1/EN 60974-10. Forced-air cooling for non-stop use.
Continuous current control by means of a graduated scale knob. Automatic protection against
overheating with automatic reset.
Voltage 230 V - 50/60 Hz. SCHUKO plug. Loadless voltage 70V. Class H insulation. Suitable for
welding with all kinds of electrodes (except those containing cellulose). Supplied with transport
case, helmet with adiactinic glass, welding cap and brushes, electrode holder andearth clamp
with 3 + 2m cable cross section 16mm² and joints Ø 25mm.
Max absorbed power by
kW
2
Min÷max electrode
mm 1,6-3,2
Min/max current regulation
A
10-140
Weight approx.
Kg
4,5
Dimensions
mm 130x270x225h
3271A
Each
602,00
vuoto
INVERTERWELDINGMACHINES
3271E
Professional electric welding machines, with monophasic alternate current. Compliant with
European specifications EN 60974-1/ EN 60974-10. Forced air-cooling for continuous use.
Continuous electronic current control by means of a graduated scale knob. Automatic protection
against overheating with automatic reset.
Voltage 230 V - 50/60 Hz. SCHUKO type plug. Loadless voltage 80 V. Insulation class H. For
welding using all types of electrode (excluding those containing cellulose). Supplied with helmet
with adiactinic glass, welding cap and brushes, electrode holder and earth clamp with 3 + 2m
cable cross section 16mm² and joints Ø 25mm.
Max absorbed power by
kW 3,5
Min÷max electrode
mm 1,6-4
Min/max current regulation
A
10-160
Weight approx.
Kg
4,8
Dimensions
mm 135x370x260h
3271E
Each 739,00
The technical characteristics of Art. 3271 A - E
are subject to possible changes by the manufacturer.
vuoto
INVERTERWELDINGMACHINES
3271L
IP23
Professional electric welding machines, monophasic alternate current. Conform to European
specifications EN 60974-1/EN 60974-10. Forced-air cooling for non-stop use. Continuous current
control by means of a graduated scale knob. INVERTER full bridge configuration.
Remote control with 5m extension for potentiometer control.
Voltage 230 V - 50/60 Hz. SCHUKO plug. Loadless voltage 65/70V. Class H insulation. Degree of
protection: IP 23. Suitable for welding with all kinds of electrodes (except those containing
cellulose). Supplied with helmet with adiactinic glass, welding cap and brushes, electrode holder
and earth clamp with 3 + 2m cable cross section 25mm² and joints Ø 50mm.
Max absorbed power by
kW 6,9
Min÷max electrode
mm 1,6-5
Min/max current regulation
A
5-200
Weight approx.
Kg
9,5
Dimensions
mm 135x390x280
3271L
Each 1.380,00
Product running out of stock.
vuoto
INVERTERWELDINGMACHINES
WELDING ELECTRODES
3272A
Prod. SCU
Rutile-coated type, according to E 6013 specification. Suitable for welding iron, building steel,
pressurized reservoirs etc. Suitable for welding machines Art. 3269 B a 3271 L and portable
welding machine with standard voltage (45 V min.). In packing units, not sold separately.
Ø
mm
1,5
2
2,5
3,25
4
Length
mm 300
300
300
450
450
Indivisible pck.
Pz
250
400
250
150
100
Pck. weight
Kg
1,8
4,3
4,2
6,5
6,4
3272A
Per pack 43,20 42,10 29,50 51,50 48,70
vuoto
WELDINGELECTRODES
3272B
Basic coating type, according to 7018-S1 specification. Suitable for strong welding of iron, steel,
steel alloys etc. for heavy carpentry such as shipbuilding, heavy vehicles etc.. For welding
machines Art. 3270 a 3271 L and high voltage welding machines (70 V min.) In packing units, not
sold separately.
Ø
mm
2
2,5
3,25
4
Length
mm 300
300
450
450
Indivisible pck.
Pz
400
250
150
100
Pck. weight
Kg
4,8
4,3
6,0
6,0
3272B
Per pack 79,10 49,90 63,20 57,40
vuoto
WELDINGELECTRODES
