WELDING ELECTRODES
768
10
Prices in EURO - VAT not included
3272E
INOX
Type with Rutile coating with very low Carbonium level. Suitable for welding INOX, AISI 347 - 321
- 308 - 304L - 304 - 302 - 301. Suitable for welding machines Art. 3270 to 3271 L and high voltage
welding machines (50 V mon.) both with direct and alternate current. In packing units, not sold
separately.
Ø
mm
2
2,5
3,25
Length
mm 300
300
350
Indivisible pck.
Pz
240
142
77
Pck. weight
Kg
2,5
2,5
2,5
3272E
Per pack 114,00 91,20 90,50
vuoto
WELDINGELECTRODES
3272L
INOX
Titanium-coated model with very low carbon content. Suitable for welding STAINLESS steel AISI
316 - 316L - 202 - 317.
To be used with welding machines Art. 3270 to 3271 L and high voltage welding machines, (min.
50 V) both direct and alternate current. In packing units not sold separately.
Ø
mm
2
2,5
3,25
Length
mm 300
300
350
Indivisible pck.
Pz
240
142
77
Pck. weight
Kg
2,5
2,5
2,5
3272L
Per pack 127,00 110,00 107,00
vuoto
WELDINGELECTRODES
3272R
INOX
Basic-coated model with low carbon content. Suitable for welding STAINLESS steel AISI 309 -
309S - 310 310S with standard steel in dissimilar welding.
To be used with welding machines Art. 3270 to 3271 L and high voltage welding machines, (min.
50 V) both direct and alternate current. In packing units not sold separately.
Ø
mm
2,5
3,25
Length
mm 300
350
Indivisible pck.
Pz
142
77
Pck. weight
Kg
2,5
2,5
3272R
Per pack 167,00 177,00
vuoto
WELDINGELECTRODES
ELECTRODE-HOLDERS
3277
Prod. SCU
Straight type with electrode-holder jaws. Made of heavy brass. Totally insulated.
Cable connection inside the handle. Electrodes may be clamped in any direction. Conform to
European specifications EN 60974-11.
Size
200
350
500
700
Capacity at 60%
A 150
200
250
300
For electrodes up to Ø mm 3,2
3,2
5
6,3
Max cable section Ø mm2 25
35
50
70
3277
Each 10,70 14,50 17,20 20,90
vuoto
ELECTRODE-HOLDERS
3277G
Straight type with electrode-holder jaws. Totally insulated. Handle is made of special sintered
material, fire-proof, shatter-proof with high insulating power.
Jaws are externally insulated through a thick protection. Strong spring.
Conform to European specifications EN 60974-11.
Fine max load capacity
A
200
300
400
600
For electrodes up to Ø mm 3
4
4
6
3277G
Each 13,70 15,40 18,50 22,30
vuoto
Insulated protections for Art. 3277 G.
Fine max load capacity
A
200
300
400
600
O3277G
Per pair
2,76
4,02
4,02
4,98
vuoto
ELECTRODE-HOLDERS
3277S
Straight type with electrode-holder hole. Totally insulated, including the lever.
Fiber-glass handle and tip with strongly insulated head.
Conform to European specifications EN 60974-11.
Size
300
400
500
600
Capacity at 60%
A 150
200
250
300
For electrodes up to Ø mm 3,2
4
5
6,3
Max cable section Ø mm2 25
35
50
70
3277S
Each 19,90 22,40 25,40 27,50
vuoto
ELECTRODE-HOLDERS
3277V
Bent type with electrode-holder hole. Made of brass. Totally insulated.
Cable locking ring. Conform to European specifications EN 60974-11.
Size
400
600
Capacity at 60%
A 200
300
For electrodes up to Ø mm 4
6,3
Max cable section Ø mm2 35
70
3277V
Each 45,50 52,30
vuoto
