827 / 1378
827
AIRVISION L COMBINATION AIR TREATMENT UNITS
827
10
Prices in EURO - VAT not included
3461GP
Orig. Ewo - Art. 462
AIRVISION L LUBRICATORS FOR COMPRESSED AIR
Modular model with small dimensions. With pilot light to check oil falling. Polycarbonate
unbreakable glass. Max operating temperature 50 °C.
Drive
inches 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 135
Dimensions (E)
mm 47
3461GP
Each 29,10
Standard operating pressure: 6 bar (Atm).
vuoto
AIRVISION LCOMBINATIONAIRTREATMENTUNITS
3461GP 3
Orig. Ewo - Art. 465
AIRVISION L FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 3 pieces with the same features of the elements Art. 3461 GL-M-P. Adjustable
from 0.5 to 10 bar (Atm).
Drive
inches 1/4
Dimensions (A)
mm 120
Dimensions (B)
mm 170
Dimensions (E)
mm 69
3461GP 3
Each 103,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIRTREATMENTUNITS
3461GP 5
Orig. Ewo - Art. 464
AIRVISION L FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 2 pieces with the same features of the elements Art. 3461 GL-M-P. Adjustable
from 0,5 to 10 bar (Atm).
Drive
inches 1/4
Dimensions (A)
mm 80
Dimensions (B)
mm 178
Dimensions (E)
mm 79
3461GP 5
Each 88,90
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIRTREATMENTUNITS
3461GR
Orig. Ewo - Art. 463
AIRVISION L FILTER-REGULATOR COMBINATIONS
Combination of 1 piece with the same features of the elements Art. 3461 GL-M.
Drive
inches 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 160
Dimensions (E)
mm 65
3461GR
Each 54,50
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIRTREATMENTUNITS
AIRVISION COMBINATION AIR TREATMENT UNITS
3462GA
Orig. Ewo - Art. 445-7445
AIRVISION FILTERS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T-V. Supplied with manual drain valve. Polyethylene porous filter 50µm.
Body in metal alloy (zinc/cast iron). Polycarbonated unbreakable glass.
Max operating temperature 50°C.
Drive
inches
1/8
1/4
3/4
1
Dimensions (A)
mm 40
40
70
70
Dimensions (B)
mm 120
120
215
215
Dimensions (E)
mm 25
25
35
35
3462GA
Each 41,60 41,60 136,00 136,00
Standard operating pressure: 6 bar (Atm).
Sizes 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIR TREATMENTUNITS
