828 / 1378
828
AIRVISION COMBINATION AIR TREATMENT UNITS
828
10
Prices in EURO - VAT not included
3462GE
Orig. Ewo - Art. 444-7444
AIRVISION REGULATORS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T-V. Body in metal alloy (zinc/cast iron). Supplied with manometer.
Adjustable from 0.5 to 10 bar (Atm). Max operating temperature 50 °C.
Drive
inches
1/8
1/4
3/4
1
Dimensions (A)
mm 40
40
70
70
Dimensions (B)
mm 90
90
145
145
Dimensions (E)
mm 25
25
41
41
3462GE
Each 55,80 55,80 183,00 182,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Sizes 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GH
Orig. Ewo - Art. 446-7446
AIRVISION LUBRICATORS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T. With pilot light to check oil falling.
Body in metal alloy (zinc/cast iron). Polycarbonate unbreakable glass.
Max operating temperature 50 °C.
Drive
inches
1/8
1/4
1/2
3/4
1
Dimensions (A)
mm 40
40
62
70
70
Dimensions (B)
mm 140
140
175
230
230
Dimensions (E)
mm 50
50
60
65
65
3462GH
Each 45,40 45,40 78,40 140,00 140,00
Standard operating pressure: 6 bar (Atm).
Sizes 1/2 - 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GP
Orig. Ewo - Art. 450-7450
AIRVISION FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 3 pieces with the same features of the elements Art. 3462 GA-E-H.
Drive
inches
1/8
1/4
3/8
1/2
3/4
1
Dimensions (A)
mm 120
120
186
186
210
210
Dimensions (B)
mm 160
160
220
220
274
274
Dimensions (E)
mm 65
65
95
95
100
100
3462GP
Each 156,00 156,00 270,00 270,00 486,00 483,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Sizes 3/8 - 1/2 - 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GT
Orig. Ewo - Art. 449-7449
AIRVISION FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 2 pieces with the same features of the elements Art. 3462 GA-E-H.
Drive
inches
1/8
1/4
3/4
1
Dimensions (A)
mm 80
80
140
140
Dimensions (B)
mm 160
160
270
270
Dimensions (E)
mm 65
65
100
100
3462GT
Each 125,00 125,00 399,00 398,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Sizes 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GV
Orig. Ewo - Art. 443-7443
AIRVISION FILTER-REGULATOR COMBINATIONS
Combination of 1 piece with the same features of the elements Art. 3462 GA-E.
Drive
inches
1/8
1/4
3/8
3/4
1
Dimensions (A)
mm 40
40
62
70
70
Dimensions (B)
mm 160
160
220
270
270
Dimensions (E)
mm 65
65
95
100
100
3462GV
Each 73,10 73,10 133,00 244,00 244,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Sizes 3/8 - 3/4 and 1 running out of stock.
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
