LAN-TESTERS AND MULTIMETERS
989
11
Prices in EURO - VAT not included
LAN-TESTERS AND MULTIMETERS
4480GP
Prod. SCU
Electronic digital model for LAN network and multimeter function test con portata automatica.
Switch for selecting functions and measurements Automatic polarity. Reading on display of
multimeter functions. LED displays the real pin configuration of 10BASE-T and 10BASE-2 Thin
Ethernet, FJ45/RJ11 modular, 58A, tia-568a/568b and Token Ring cables (ring network).
Provides easy to read continuity and fault status display. Checks for continuity, open wire, ground
wire, shorted pair and crossed pair faults. Auto or manual scanning for LAN testing.
Test diode.
Discharged battery indication.
Continuous current: capacity 200 mV to 600 V/ 200,0 µA to 200,0 mA
Alternate current 50-60 Hz: capacity 2.000 V to 20.00 V - 200.0 V to 600 V/200.0 µA to 200.0 mA
Resistance: capacity 200.0 ohm to 20.00 Mohm
Power supply: 1 9V alkaline battery (Art. 3600 M) and 2 alkaline batteries 1.5 V "AAA" (Art. 3600
C), supplied.
With pointer couple, LAN test cable, 2 x female cables BNC-RS 45 and double male adapter BNC.
4480GP
Each 139,00
vuoto
LAN-TESTERSANDMULTIMETERS
DIGITAL MULTIMETERS WITH TACHOMETERS
4480GV
Prod. SCU
Digital electronic model with double function, with the ability to measure current (multimeter) and
catch the speed (speedometer).
Selection of the functions of the measures through the switch.
AC voltage: 400 mV-4/40/400/1000 V
DC voltage: 4/40/400/700 V
alternating current: 40/400 mA-4/20 A
DC current: 40/400 mA-4/20 A
resistance: 400 ohms-4/40/400 K?-4/40 Mohm
capacity: 40/400 nF-4/40/100 µF
frequency: 5/50/500 Hz-50/500-10 MHz
Duty Cycle: 0.1-99.9%
Pulse Amplitude: 1-10 ms
diode Test test current: 0.3 but
continuity: 1500 ohm-BIE < test < 0.3 but
4600 RPM-4000 RPM
-4600 RPM 12000 RPM (x 10 RPM)
2 RPM/DIS 300-4000 RPM
2 RPM/DIS 300-6000 RPM
Power: included 1 alkaline 9 V battery (see Art. 3600 M)
for battery saving auto-off
reading on high-contrast display 4 digit, back-illuminated.
Complete with tips and inductive clamp torque.
4480GV
Each 215,00
For spare pairs of toes for Art. 4479 G/GE - 4480 G/GB/GE/GV - 4481 G/GB/GC/GD/GDE/GE see Art. OP 4479 GE.
vuoto
DIGITALMULTIMETERSWITHTACHOMETERS
CURRENT TESTERS
4481G
Prod. SCU
Analogue model.
For measurement of alternate currents, alternate voltage, continuous voltage, resistance.
Manual locking of the index after measurement.
Made of shock-proof plastic, very high insulation.
Continuous voltage: 0 to 60 V.
Alternate Voltage / Current:150 to 600 V / 6 to 300 A .
Resistance: 0-10 K ohm.
Power: included 1 alkaline 1,5 V battery AAA type (Art. 3600 C). Max. aperture 32mm.
With 2 pointers.
4481G
Each 88,20
vuoto
CURRENTTESTERS
