DIGITAL HARDNESS TESTERS
992
11
Prices in EURO - VAT not included
DIGITAL HARDNESS TESTERS
4481GSE
Prod. SCU
Digital model with bright, large, multifunction display to measure the hardness of steel, cast iron,
aluminum, non-ferrous materials. Portable for max flexibility and ease of transportation, provided
with special separated sensor allowing easy measurements even in hard-to-reach. Usable in any
orientation (360°), automatic angle compensation. In compliance with ASTM A-956 and DIN
50156.
It allows visualization of measurements in Leeb scale (HL) and automatic conversion to: Rockwell
(B and C), Vickers (HV), Brinell (HB), Shore (HSD) scale as well as traction resistance (MPa-Ob).
It allows statistical measurements with visual indication of absolute values, average value (up to 9
measurements), diference between min. and max. values (tolerance), time and date. Instant
printing of measured values via IR-link printer (cordless), included. Indicated for flat, concave/
concex objects with radii > 10mm (via dedicated stabilizing ring) or > 50mm (without ring),
thickness > 8mm and mass > 3kg.
Operated by No.3 x 1.5 V alkaline batteries (AAA-typ - Art. 3600 C), included, or by network
power supply V 230 - Hz 50 (included).
Automatic switch-off and battery level indicator.
Supplied in robust transport case, complete with calibration sample.
Roughness capacity
HL 170 to 960
Resistance to traction capacity (with steel)
MPa-Ob 375 to 2639
4481GSE
Each 2.370,00
vuoto
DIGITALHARDNESSTESTERS
HARDNESS TESTERS
4481GTA
Prod. SCU
With dial, to measure the hardness of soft materials such as rubbers, caouthouc, plastic
materials, resins, etc. in measurement units SHORE A.
Scale: 0 ÷ 100. Steel contact point.
4481GTA
Each 73,30
vuoto
HARDNESSTESTERS
4481GVA
With dial, value indicator, high-precision, 1% of max. value, in compliance with DIN 53505 / ASTM
- D - 2240 / ISO 868 standards. Complete with gauged tester for periodial check of calibration.
Scale: 0 ÷ 100. Increments 1 unit. Steel contact point. Dimensions 115x60x25mm, weight 160g.
With case.
SHORE A scale to measure materials such as rubbers, elastomers, neoprene, silicon, vinyl, soft
plastics, leather, felt, etc.
4481GVA
Each 160,00
vuoto
HARDNESSTESTERS
4481GVE
Product description as Art. 4481GVA
SHORE C/0 scale for foam and sponge measurements.
4481GVE
Each 211,00
vuoto
HARDNESSTESTERS
