1134
Prices in EURO - VAT not included
1134
STUB DRILLS, RIGHT HAND CUTTING
13
8461G
HSS-E
Orig. Hartner - Art. 84804
Spiral flute length according to DIN 338. Type FU 500 DZ. COBALT HSS-E. Cutting angle 118°.
SHORT pattern.
Particular 4 facet sharpening and special web thinning for low turning moments, higher drilling
parameters and good finishing of the hole surface.
For alloyed and unalloyed steel up to R 850 N/m², steel for hot/cold working, ball bearing steel,
stainless steel, non-ferrous metals, cast iron and plastic material.
Cylindrical shank
Ø
mm
1,0 1,2 1,5 1,6 1,7 2,0 2,4 2,5 2,8 3,0 3,2 3,3 3,5 3,6 3,7
Overall length
mm 34
38
40
43
43
49
57
57
57
61
65
65
70
70
70
Helix length
mm 12
16
18
20
20
24
30
30
30
33
36
36
39
39
39
8461G
Each 2,44 2,44 2,44 2,44 2,44 2,60 2,60 2,66 2,78 2,66 2,78 2,88 3,06 3,06 3,06
Ø
mm
3,8 4,0 4,1 4,2 4,3 4,5 4,6 4,8 4,9 5,0 5,1 5,2 5,5 6,0 6,2
Overall length
mm 75
75
75
75
80
80
80
86
86
86
86
86
93
93 101
Helix length
mm 43
43
43
43
47
47
47
52
52
52
52
52
57
57
63
8461G
Each 3,34 3,28 3,34 3,34 3,42 4,38 3,42 3,42 3,56 3,56 3,56 3,68 3,82 4,24 4,82
Ø
mm
6,5 6,6 6,8 7,0 7,4 7,5 7,9 8,0 8,5 9,0 9,3 9,5 9,8 10,0 10,2
Overall length
mm 101 101 109 109 109 109 117 117 117 125 125 125 133 133 133
Helix length
mm 63
63
69
69
69
69
75
75
75
81
81
81
87
87
87
8461G
Each 4,82 5,26 6,12 5,98 7,34 6,40 8,06 6,70 7,12 8,06 10,30 9,00 11,50 10,30 13,40
Ø
mm
10,5 11,0 11,5 12,0 12,5 13,0 13,5 14,0
Overall length
mm 133 142 142 151 151 151 160 160
Helix length
mm 87
94
94 101 101 101 108 108
8461G
Each 13,40 15,50 17,70 18,70 22,70 26,60 30,60 32,10
vuoto
STUBDRILLS,RIGHTHANDCUTTING
8463G
HSS-E
TIN
Orig. Hartner
Spiral flute length according to DIN 338. Type FU 500 DZ. COBALT HSS-E+TIN. Cutting angle
118°. SHORT pattern.
Particular 4 facet grinding and special web thinning for low turning moments, higher drilling
parameters and good finishing of the hole surface.
For alloy and unalloyed steel up to R 850 N/sqmm, steel for hot/cold working, bearing steel,
stainless steel, non-ferrous metals, cast iron and plastic materials.
Cylindrical shank. TIN treatment.
Ø
mm
2 2,5 3 3,3 3,5 4 4,2 4,5 5 5,5 6 6,5 6,8 7 7,5 8 8,5
Overall length
mm 49 57 61 65 70 75 75 80 86 93 93 101 109 109 109 117 117
Helix length
mm 24 30 33 36 39 43 43 47 52 57 57 63 69 69 69 75 75
Drive Ø
mm 2 2,5 3 3,3 3,5 4 4,2 4,5 5 5,5 6 6,5 6,8 7 7,5 8 8,5
Drive length
mm -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Supplier code ............
84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84802
8463G
Each 5,98 6,12 6,54 7,26 7,84 8,06 8,34 8,70 9,28 11,10 11,30 13,40 15,10 15,10 15,90 18,10 18,70
Ø
mm
9 9,5 10 10,2 10,5 11 11,5 12 13 14 15 16 17 18 19 20
Overall length
mm 125 125 133 133 133 142 142 151 151 160 169 172 181 184 188 191
Helix length
mm 81 81 87 87 87 94 94 101 101 108 109 112 115 118 122 125
Drive Ø
mm 9 9,5 10 10,2 10,5 11 11,5 12 13 14 16 16 20 20 20 20
Drive length
mm -
-
-
-
-
-
-
-
-
-
48 48 50 50 50 50
Supplier code ............
84802 84802 84802 84802 84802 84802 84802 84802 84802 84802 84801 84801 84801 84801 84801 84801
8463G
Each 20,90 22,10 24,10 28,40 28,40 29,20 32,80 34,20 38,10 46,10 263,00 281,00 296,00 326,00 368,00 383,00
vuoto
STUBDRILLS,RIGHTHANDCUTTING
8464G
HSS-E
FIRE
Orig. Hartner - Art. 84507
Spiral flute length according to DIN 338. Type FN 500 DZ. COBALT HSS-E + FIRE. Cutting angle
130°. SHORT pattern. High-performance drills, excellent heat resistance, wide slots. Produced by
using the powder-sintering technique (PM), such drills combine the advantages of conventional
Cobalt HSS-E and solid carbid drills, resulting cheaper and less subject to breakage. FIRE-coated
surface, for high-speed working, dry working, or when using nebulized lubrication-cooler.
For high-percentage alloy steel, quenched and tempered steel and case hardening steel, cast
iron, brass and bronze.
Cylindrical shank according to DIN 1835A. FIRE treatment.
Ø
mm
2
2,5
3
3,3 3,5
4
4,2 4,5
5
5,5
6
6,5*
6,8
7
7,5
Overall length
mm 56
62
65
68
71
75
87
91
96 101 101 107 113 113 113
Helix length
mm 24
30
33
36
39
43
43
47
52
57
57
63
69
69
69
Drive Ø
mm 3
3
3
4
4
4
6
6
6
6
6
8
8
8
8
Drive length
mm 28
28
28
28
28
28
36
36
36
36
36
36
36
36
36
8464G
Each 22,60 26,70 26,70 29,70 29,70 33,20 40,70 39,20 49,10 49,10 53,50 65,60 69,30 69,30 70,80
Ø
mm
8
8,5
9
9,5*
10 10,2* 10,5*
11 11,5 12 13*
Overall length
mm 119 125 131 131 137 144 144 151 151 158 161
Helix length
mm 75
75
81
81
87
87
87
94
94 101 101
Drive Ø
mm 8
10
10
10
10
12
12
12
12
12
14
Drive length
mm 36
40
40
40
40
45
45
45
45
45
48
8464G
Each 75,40 84,40 75,40 81,40 88,90 112,00 112,00 106,00 112,00 122,00 162,00
* Sizes running out of stock
