1272
Prices in EURO - VAT not included
1272
INOX THREADED RIVETS
13
9500GE
INOX
BSW
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø BSW
inch
1/8
3/16
1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr.
40
24
20
18
16
14
12
Supplier code ....................
08341 08342 08343 08344 08345 08346 08347
9500GE
Each 0,92
0,92
0,38
0,46
0,76
0,94
0,94
vuoto
INOXTHREADEDRIVETS
9500GF
INOX
BSF
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø BSF
inch
3/16
1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr.
32
26
22
20
18
16
Supplier code ....................
08362 08363 08365 08366 08367 08368
9500GF
Each 0,92
0,38
0,46
0,76
0,94
0,94
vuoto
INOXTHREADEDRIVETS
9500GL
INOX
BSP
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Up to Ø 1/2" inch, packs of 50 pcs, not sold separately; from Ø 5/8" inch, packs of 5 pcs, not sold
separately.
Thread Ø BSP (G)
inch
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
Nr.
28
19
19
14
14
14
11
Supplier code ....................
08380 08381 08382 08383 08384 08385 08387
9500GL
Each 0,58
0,86
1,00
1,28
3,20
3,20
9,84
vuoto
INOXTHREADEDRIVETS
9501G
M
MF
TAPS FOR THREADED INSERTS
Special type for housing threaded inserts Art. 9500 G.
For int Ø
mm
3
4
5
6
7
8
8
9
10
10
10
12
12
12
Pitch
mm
0,5
0,7
0,8
1
1
1
1,25 1,25
1
1,25 1,5
1
1,25 1,5
Pre-hole Ø
mm 3,2
4,2
5,2
6,3
7,3
8,3
8,3
9,3 10,3 10,3 10,4 12,3 12,3 12,4
Supplier code.....................
03005 0
3007 03008 03009
03010 03012 03011 03013 03017 03016 03015 03023 03022 03021
9501G
Each 8,26 8,26 8,26 8,26 10,30 10,30 10,30 12,60 12,60 12,60 12,60 17,40 17,40 17,40
For int Ø
mm
12
14
14
14
16
16
18
20
20
22
24
24
24
Pitch
mm
1,75 1,25 1,5
2
1,5
2
2,5
2
2,5
2,5
1,5
2
3
Pre-hole Ø
mm 12,4 14,5 14,5 14,5 16,4 16,5 18,6 20,5 20,6 22.6 24,5 24,5 24,75
Supplier code.....................
03020 03029 03028 03027 0303 03033 03035 03039 03038 03041 03046 03045 03044
9501G
Each 14,30 19,80 19,80 19,80 25,10 25,10 31,40 34,60 34,60 39,90 50,30 50,30 50,30
vuoto
INOXTHREADEDRIVETS
9501GA
UNC/NC
Special type for housing threaded inserts Art. 9500 GA.
For threads UNC
inch
Nr. 2 Nr. 4 Nr. 5 Nr. 6 Nr. 8 Nr. 10 Nr. 12
Pre-hole Ø
mm 2,4
3,0
3,4
3,7
4,4
5,1
5,7
Supplier code ....................
03100 03101 03102 03103 03104 03105 03106
9501GA
Each 12,60 12,60 12,60 12,60 12,60 12,60 12,60
For threads UNC
inch
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 6,7
8,3
9,9
11,6
13,0
Supplier code ....................
03107 03108 03109 03110 03111
9501GA
Each 8,26
8,98
9,40 12,60 14,30
vuoto
INOXTHREADEDRIVETS
9501GB
UNF/NF
Special type for housing threaded inserts Art. 9500 GB.
For threads UNF
Nr. 4 Nr. 6 Nr. 8 Nr. 10 1/4
5/16
3/8
Pre-hole Ø
mm 3,0
3,7
4,4
5,1
6,6
8,2
9,8
Supplier code ....................
03151 03152 03153 03154 03155 03156 03157
9501GB
Each 12,60 12,60 12,60 12,60 8,26
8,98
9,40
For threads UNF
7/16
1/2
Pre-hole Ø
mm 11,5
13,0
Supplier code ....................
03158 03159
9501GB
Each 12,60 14,30
vuoto
INOXTHREADEDRIVETS
