1273
Prices in EURO - VAT not included
1273
INOX THREADED RIVETS
13
9501GE
BSW
Special type for housing threaded inserts Art. 9500 GE.
For threads BSW
inch
1/8
3/16
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 3,4
5,1
6,7
8,3
9,9
11,6
13,0
Supplier code.....................
03201 03202 03203 03204 03205 03206 03207
9501GE
Each 8,26
8,26
8,26
8,98
9,40 12,60 14,30
vuoto
INOXTHREADEDRIVETS
9501GF
BSF
Special type for housing threaded inserts Art. 9500 GF.
For threads BSF
inch
3/16
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 5,0
6,6
8,3
9,9
11,6
13,0
Supplier code.....................
03251 03253 03255 03256 03257 03258
9501GF
Each 8,26
8,26
8,98
9,40 12,60 14,30
vuoto
INOXTHREADEDRIVETS
9501GL
BSP
Special type for housing threaded inserts Art. 9500 GL.
Thread BSB (G)
1/8
1/4
3/8
1/2
5/8
3/4
1
Pre-hole Ø
mm 10
13,60 17,10 21,50 23,40
27
33,70
Supplier code.....................
03301 03302 03303 03304 03305 03306 03307
9501GL
Each 11,90 15,10 19,40 31,70 46,50 46,50 74,10
vuoto
INOXTHREADEDRIVETS
9502GA
APPLICATION TOOLS
For mounting threaded inserts Art. 9500 G to 9500 GF.
Size
2
4
5
6
7
For metric inserts
M 2x0,4 and 2,2x0,45
3x0,5
3,5x0,6
4x0,7
-
For inserts with threads
UNC Nr. 2
UNC Nr. 5, UNC/UNF Nr. 4,
BSW 1/8
UNC/UNF Nr. 6
UNC/UNF Nr. 8
UNC Nr. 10, BSW 3/16
Supplier code.....................
08002
08004
08005
08006
08007
9502GA
Each
8,12
8,12
8,12
8,12
8,12
Size
8
9
10
11
12
For metric inserts
M
5x0,8
6x1
7x1
8x1 and 8x1,25
9x1 and 9x1,25
For inserts with threads
UNF Nr. 10, UNC Nr. 12,
BSF 3/16
UNC/UNF/BSW/BSF 1/4
UNC/BSW 5/16
UNF/BSF 5/16
UNC/BSW 3/8
Supplier code.....................
08008
08009
08010
08011
08012
9502GA
Each
8,12
8,12
9,26
9,26
9,98
Size
13
14
15
16
17
For metric inserts
M 10x1, 10x1,25, 10x1,5
11x1,25 and 11x1,5
12x1, 12x1,25, 12x1,5,
12x1,75
14x1,5 and 14x2
14x1 and 14x1,25
For inserts with threads
UNF/BSF 3/8
UNC/UNF/BSW/BSF 7/16 UNC/UNF/BSW/BSF 1/2 UNC/UNF/BSW/BSF 9/16
-
Supplier code.....................
08013
08014
08015
08016
08017
9502GA
Each
9,98
11,70
11,70
14,10
14,10
Size
18
20
21
22
23
For metric inserts
M 16x1,5 and 16x2
18x1,5, 18x2, 18x2,5
20x1,5, 20x2, 20x2,5
22x1,5, 22x2, 22x2,5
24x1,5, 24x2, 24x3
For inserts with threads
UNC/UNF/BSW/BSF 5/8
UNC/BSW/BSF 3/4
UNF 3/4
UNC/UNF/BSW/BSF 7/8 UNC/UNF/BSW/BSF 1"
Supplier code.....................
08018
08020
08021
08022
08023
9502GA
Each
15,40
15,40
15,40
19,40
19,40
vuoto
INOXTHREADEDRIVETS
9502GAR
1/4 ,,
APPLICATION TOOLS WITH HEXAGONAL JOINT 1/4 DIN 3126 C6,3
Handy or machine application, to install threaded inserts Art. 9500 G as well as all inside
threaded bushings from M 3 to M 12.
For metric inserts
M
3
4
5
6
8
10
12
Hexagonal drive
inch 1/4
1/4
1/4
1/4
1/4
1/4
1/4
Supplier code.....................
08091 08092 08093 08094 08095 08096 08097
9502GAR
Each 8,12
8,12
8,12
8,12
9,26
9,98 11,70
vuoto
INOXTHREADEDRIVETS
9502GAS
1/4 ,,
1/2 ,,
APPLICATION TOOLS WITH HEXAGONAL JOINT 1/4-1/2 DIN 3126 C6,3
Handy or machine application, to install threaded inserts Art. 9500 GL as well as all inside
threaded bushings from BSP (G) 1/8" to 1".
For BSP (G) inserts
inch
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
Nr.
28
19
19
14
14
14
11
Hexagonal drive
inch 1/4
1/4
1/4
1/4
1/2
1/2
1/2
Supplier code.....................
08080 08081 08082 08083 08084 08085 08087
9502GAS
Each 13,30 13,30 15,40 17,70 22,10 22,10 30,80
vuoto
INOXTHREADEDRIVETS
