442
Prices in EURO - VAT not included
6
442
DIN 2080 MILLING CUTTER HOLDER CHUCKS WITH FIXED DRAGGING
DIN 2080 MILLING CUTTER HOLDER CHUCKS WITH FIXED DRAGGING
1560GAC
Prod. SCU
For milling cutters with hole connection. High-precision, max centring of milling cutters with the
highest torque.
DIN 2080 shank, internally threaded end.
d mills bore Ø
mm
16
22
27
32
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 40 M16
ISO 40 M16
Height L
mm
17
19
21
24
Height L1
mm
36
36
36
45
Height d1
mm
32
40
48
63
1560GAC
Each
107,00
107,00
107,00
107,00
For cross-shaped clamping wrenches see Art. 911 GP.
vuoto
DIN 2080MILLINGCUTTERHOLDERCHUCKSWITH FIXEDDRAGGING
DIN 2080 MORSE CONE REDUCTION CHUCKS FOR MILLING CUTTERS
1560GAE
Prod. SCU
For milling cutters with Morse taper shank, internally threaded. High-precision, max centring of
milling cutters with the highest torque.
DIN 2080 shank, internally threaded end.
Mills drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 40 M16
ISO 40 M16
Height L
mm
50
50
65
95
Height D
mm
25
32
40
48
1560GAE
Each 153,00
153,00
153,00
163,00
vuoto
DIN 2080MORSECONEREDUCTIONCHUCKSFORMILLINGCUTTERS
DIN 2080 MORSE CONE REDUCTION CHUCKS FOR DRILLS
1560GAF
Prod. SCU
For drill bits with Morse taper shank. High-precision, max centring of drill bits with the highest
torque.
DIN 2080 shank, internally threaded end.
Tips drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
ISO 40 M16
ISO 40 M16
Height L
mm
50
50
65
95
Height D
mm
25
32
40
48
1560GAF
Each
151,00
151,00
151,00
156,00
vuoto
DIN 2080MORSECONEREDUCTIONCHUCKSFORDRILLS
DIN 2080 MONOLITHIC DRILL CHUCKS
1560GAL
Prod. SCU
For drill bits with cylindrical shank. High-precision, max centring of drill bits with the highest
torque.
DIN 2080 shank, internally threaded end.
For tips Ø up to
mm
13
16
Shape/ thread K/G
ISO 40 M16
ISO 40 M16
Height L
mm
87
100
Height D
mm
51
58
1560GAL
Each
418,00
438,00
vuoto
DIN 2080MONOLITHICDRILLCHUCKS
